Use the following tables to determine the correct Evaporator Pressure Drop Curve for selected units.
DCC Evaporator Pressure Drop
Units Evap Num
98 DCC047DR-08EPV0 2
99 DCC049DR-08EYY0 2
100 DCC049DR-10EPV0 2
101 DCC051DR-10EYY0 2
102 DCC052DR-09DYV0 4
103 DCC056DR-10DVV0 6
104 DCC058DR-10DVW0 5
105 DCC061DR-10DWW0 8
106 DCC065TR-10GPPY 12
107 DCC050DR-12EPV0 2
108 DCC052DR-12EYY0 2
109 DCC054DR-11DYV0 4
110 DCC058DR-12DVV0 6
111 DCC060DR-12DVW0 5
112 DCC063DR-12DWW0 8
113 DCC069TR-11GPYY 11
114 DCC074TR-12GYYY 13
115 DCC056DR-13DYV0 4
116 DCC059DR-14DVV0 6
117 DCC061DR-14DVW0 5
118 DCC065DR-14DWW0 8
119 DCC068TR-13GPPY 12
120 DCC072TR-14GPYY 11
121 DCC077TR-13GYYV 13
122 DCC080TR-14GYVV 13
123 DCC070TR-16GPPY 12
124 DCC077TR-15GYYY 13
125 DCC080TR-16GYYV 13
126 DCC083TR-15GVVV 13
127 DCC086TR-15GVVW 14
128 DCC088TR-15GVWW 14
129
DCC091TR-
15GWWW 14
130 DCC074TR-17GPYY 11
131 DCC079TR-18GYYY 13
132 DCC082TR-17GYVV 13
133 DCC085TR-18GVVV 13
134 DCC088TR-18GVVW 14
135 DCC091TR-18GVWW 14
136
DCC094TR-
18GWWW 14
137 DCC082TR-19GYYV 13
138 DCC084TR-20GYVV 13
139 DCC087TR-21GVVV 13
140 DCC090TR-21GVVW 14
141 DCC093TR-21GVWW 14
Units Evap Num
142
DCC096TR-
21GWWW 14
143 DCC048DX-10EPV0 2
144 DCC049DX-10EYY0 2
145 DCC049DX-12EPV0 2
146 DCC051DX-12EYY0 2
147 DCC053DX-11DYV0 4
148 DCC056DX-12DVV0 6
149 DCC058DX-12DVW0 5
150 DCC061DX-12DWW0 8
151 DCC050DX-14EPV0 2
152 DCC052DX-14EYY0 2
153 DCC054DX-13DYV0 4
154 DCC057DX-14DVV0 6
155 DCC060DX-14DVW0 5
156 DCC063DX-14DWW0 8
157 DCC066TX-13GPPY 12
158 DCC070TX-14GPYY 11
159 DCC055DX-15DYV0 4
160 DCC059DX-16DVV0 6
161 DCC061DX-16DVW0 5
162 DCC065DX-16DWW0 8
163 DCC068TX-16GPPY 12
164 DCC075TX-15GYYY 13
165 DCC077TX-16GYYV 13
166 DCC072TX-17GPYY 11
167 DCC077TX-18GYYY 13
168 DCC080TX-17GYVV 13
169 DCC083TX-18GVVV 13
170 DCC086TX-18GVVW 14
171 DCC088TX-18GVWW 14
172 DCC091TX-18GWWW 14
173 DCC070TX-19GPPY 12
174 DCC074TX-20GPYY 11
175 DCC079TX-21GYYY 13
176 DCC080TX-19GYYV 13
177 DCC081TX-22GYYV 13
178 DCC082TX-20GYVV 13
179 DCC085TX-21GVVV 13
180 DCC088TX-21GVVW 14
181 DCC091TX-21GVWW 14
182 DCC094TX-21GWWW 14
