Speciers Guide 9
Nomenclature 9
Introduction 9
Range Layout 10
Unit Overview 12
Construction 14
Refrigeration 14
Compressor 14
Refrigeration Pipework Components 14
Electronic Expansion Valves (EEV) 15
Condenser Coils 16
Corrosion Resistant Coated Coils 16
Evaporator 16
Electrical 17
Phase Rotation Protection 18
Single Point Isolation 18
Electronic Soft Start 18
Control Panel Light 19
Mains Cable Entry 19
R410A Leak Detection 19
Condenser Fans 20
Condenser Fan and Motor - AC 20
Energy saving Electronically Commutated (EC) Fan Motor 20
High Airow EC Fans 20
Waterside 21
Free Cooling Coil 21
Water Flow Switch 21
Water Connections 21
Waterside Options 23
Controls 24
General Description 24
Monitoring 25
Alarm Handling 26
Compressor Fast Start 26
Displays hours run of each pump. 27
Chiller Sequence Manager 27
Energy Manager 27
Mechanical 28
Lifting Lugs 28
Extended Discharge Air Plenum - Condenser Fan 28
Anti Vibration Mounts (Spring Type) 28
Anti Vibration Mounts (Pad Type) 28
Contents
Environmental Considerations
Units with supply water temperatures below +5°C
● Glycol is recommended when a supply water temperature of +5°C or below is required or when static water can
be exposed to freezing temperatures.
Units subject to ambient temperatures lower than 0°C
● Glycol of an appropriate concentration (1) must be used within the system to ensure adequate freeze protection.
Please ensure that the concentration is capable of protection to at least 3K lower than ambient.
● Water / glycol solution should be constantly circulated through all waterside pipework and coils to avoid static
water from freezing.
● Ensure that pumps are started and running even during shut down periods, when the ambient is within 3K of the
solution freeze point (1) (i.e. if the solution freezes at 0°C, the pump must be operating at 3°C ambient).
● Additional trace heating is provided for interconnecting pipework.
(1) Refer to your glycol supplier for details.
Environmental Policy
It is our policy to:
● Take a proactive approach to resolve environmental issues and ensure compliance with regulatory requirements.
● Train personnel in sound environmental practices.
● Pursue opportunities to conserve resources, prevent pollution and eliminate waste.
● Manufacture products in a responsible manner with minimum impact on the environment.
● Reduce our use of chemicals and minimise their release to the environment.
● Measure, control and verify environmental performance through internal and external audits.
● Continually improve our environmental performance.
CE Directive
Airedale certify that the equipment detailed in this manual conforms with the following EC Directives:
Electromagnetic Compatibility Directive (EMC) 2014/30/EU
Machinery Directive (MD) 89/392/EEC version 2006/42/EC
Pressure Equipment Directive (PED) 2014/68/EU
Ecodesign 2009/125/EC
To comply with these directives appropriate national & harmonised standards have been applied. These are listed on the
Declaration of Conformity, supplied with each product.
