AIREDALE DeltaChill - DCC Mechanical Data - Extra Quiet

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
172
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
143 144 145
DCC048DX-10EPV0 DCC049DX-10EYY0 DCC049DX-12EPV0
FreeCooling No No No
Enhance Capital Allowance No No No
Number of Refrigeration Circuits 2 2 2
Cooling Duty - EC Fans
Nominal Output - Mechanical (1) kW 464.8 484.7 480.2
Nominal Input - Mechanical kW 163.8 177.7 157.5
EER (2) 2.84 2.73 3.05
ESEER 4.10 4.08 4.27
Nominal Output - Free Cooling kW N/A N/A N/A
Ambient temperature for
100% Free Cooling
(5) °C N/A N/A N/A
Capacity Steps % 25-45-65-85-100 20-35-55-70-85-100 25-45-65-80-100
Minimum Turndown Ratio 0.24 0.18 0.23
Dimensions (H x W x L) mm 2682 x 2200 x 5978 2682 x 2200 x 5978 2682 x 2200 x 7110
Weight
Machine (3) kg 4485 4620 5000
Operating kg 4755 4885 5335
Water Volume (Total Internal) l 270 265 335
Maximum Waterow l/s 29.7 29.7 29.7
Minimum Waterow l/s 6.8 6.8 6.8
Face Area (Total) m² 2.38 2.38 2.38
Nominal Airow - EC Fans m³/s 44.1 44.1 53.0
Quantity 10 10 12
Maximum Speed - EC Fans rpm 725 725 725
Compressor Tandem + Trio Trio + Trio Tandem + Trio
Quantity of Compressors 5 6 5
Oil Charge Volume (Total) l 2 x 5.3 + 3 x 5.3 3 x 5.3 + 3 x 5.3 2 x 5.3 + 3 x 5.3
Refrigeration R410A / 2088
Charge (Total) kg 24 + 34 29 + 30 28 + 37
GWP Tonnes Equivalent CO2 tCO2 50 + 71 61 + 63 58 + 77
Refrigerant Control Electronic Expansion Valve (EEV)
Water Inlet / Outlet - Unit DN125 DN125 DN125
Water Drain / Bleed - Evap inch 1/2 1/2 1/2
Water System
Minimum System Water Volume (4) l 1885 1523 1909
Maximum System
Operating Pressure
Bar 10 10 10
DCC Mechanical Data - Extra Quiet
(1) Based on units performance at 12/7°C return/supply temperatures, 35°C ambient, 100% water. All performance data supplied in accordance with BBS EN14511-1:2013
(2) EER = DX Cooling Output / (Compressor input power + Fan Input Power),
(3) Based on standard unit without options, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options tted please refer to Airedale.
(4) For minimum system volume, refer to Design Features & Information - Minimum System Water Volume Calculations
(5) Ambient temperature that full Freecool capacity can be achieved
