1 Output kW refers to the chilled water duty (Based upon 20% Ethylene Glycol).
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
50 DCF101TR-21HVWW
6 976.7 247.8 929.8 273.3 878.8 302.8 822.5 336.0
7 1005.1 249.6 957.3 275.2 905.1 304.7 847.1 337.7
8 1033.8 251.4 985.9 277.3 931.7 306.6 872.4 339.6
10 1092.3 255.3 1041.9 280.9 986.1 310.4 924.3 343.6
12 1152.0 259.2 1099.9 284.9 1042.0 314.5 977.7 347.7
14 1212.3 263.4 1158.9 289.1 1098.7 318.6 1032.7 351.9
51 DCF103TR-21HWWW
6 1000.9 259.1 952.7 285.6 901.1 316.5 843.9 351.0
7 1029.8 261.0 982.0 287.9 927.8 318.4 869.2 353.0
8 1059.1 262.9 1009.1 289.6 955.0 320.4 895.0 355.1
10 1118.4 266.9 1067.8 293.9 1010.3 324.5 947.7 359.2
12 1178.9 271.0 1125.8 297.8 1067.1 328.8 1002.0 363.5
14 1238.2 274.9 1185.6 302.2 1125.0 333.2 1057.8 367.9
52 DCF047DX-09DXY0
6 473.3 130.4 445.7 143.7 415.8 158.8 383.9 175.7
7 486.7 131.5 458.2 144.9 427.6 160.0 394.7 176.9
8 500.2 132.6 471.0 146.0 439.4 161.2 405.7 178.1
10 527.7 134.9 496.9 148.4 463.7 163.7 428.1 180.7
12 555.7 137.4 523.4 151.0 488.5 166.3 451.2 183.3
14 584.3 140.0 550.3 153.6 513.8 169.0 474.8 186.1
53 DCF049DX-09DPY0
6 490.0 134.8 461.0 148.6 429.9 164.1 396.6 181.3
7 503.7 136.0 473.9 149.8 441.8 165.3 407.6 182.5
8 517.5 137.1 486.9 151.0 453.9 166.6 418.8 183.8
10 545.6 139.6 513.4 153.6 478.6 169.2 441.6 186.5
12 574.3 142.3 540.4 156.2 503.9 171.9 465.0 189.2
14 603.5 145.0 567.9 159.0 529.7 174.7 489.0 192.1
54 DCF051DX-10DPV0
6 513.7 136.8 483.9 151.0 451.5 167.1 416.8 185.1
7 528.3 137.9 497.6 152.1 464.3 168.3 428.6 186.3
8 543.0 139.0 511.5 153.3 477.3 169.5 440.6 187.6
10 573.0 141.5 539.7 155.8 503.7 172.0 465.1 190.1
12 603.5 144.0 568.5 158.4 530.7 174.7 490.3 192.8
14 634.5 146.7 597.9 161.2 558.3 177.5 516.0 195.6
55 DCF053DX-10DYY0
6 530.3 148.7 499.8 163.9 466.8 180.9 431.5 199.7
7 545.2 149.9 513.8 165.2 479.9 182.2 443.5 201.1
8 560.3 151.2 528.0 166.5 493.1 183.6 455.8 202.4
10 590.9 153.8 556.8 169.2 520.1 186.4 480.8 205.3
12 622.2 156.6 586.3 172.1 547.7 189.3 506.4 208.2
14 654.0 159.5 616.4 175.0 575.9 192.3 532.8 211.3
56 DCF049DX-11DXY0
6 488.6 124.9 461.6 137.5 432.5 151.8 401.2 168.0
7 502.7 125.8 475.1 138.4 445.1 152.8 412.9 169.0
8 517.1 126.7 488.7 139.4 457.9 153.8 424.8 170.0
10 546.3 128.7 516.4 141.4 484.0 155.8 449.1 172.0
12
576.2 130.7 544.8 143.5 510.7 157.9 474.2 174.2
14 606.6 132.9 573.8 145.7 538.1 160.2 499.9 176.6
DCF Performance Data EC Fans
