AIREDALE DeltaChill - Page 143

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
143
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
103
DCC056DR-10DVV0
5 581.1 155.2 553.9 171.4 522.6 189.7 485.3 209.3
6 598.6 156.4 570.8 172.5 538.1 190.7 499.9 210.3
7 616.4 157.6 587.9 173.7 553.9 191.7 514.6 211.3
8 634.3 158.8 605.3 175.0 569.9 192.8 529.6 212.4
9 652.5 160.1 622.8 176.2 586.1 193.9 544.9 213.5
10 670.9 161.3 640.7 177.5 602.5 195.0 560.3 214.6
104
DCC058DR-10DVW0
5 609.4 167.5 580.3 184.6 545.9 203.7 507.0 224.7
6 627.5 168.8 597.4 185.8 561.9 204.9 521.8 225.9
7 645.7 170.1 614.7 187.0 578.0 206.0 536.9 227.1
8 664.2 171.4 632.2 188.3 594.3 207.2 552.2 228.3
9 682.9 172.8 649.9 189.6 610.8 208.5 567.8 229.5
10 701.6 174.2 667.7 190.9 627.5 209.8 583.5 230.8
105
DCC061DR-10DWW0
5 649.5 180.7 617.0 198.5 578.4 218.4 536.6 240.8
6 668.5 182.2 634.7 199.8 595.0 219.7 552.0 242.1
7 687.8 183.6 652.5 201.1 611.7 221.1 567.7 243.4
8 707.3 185.1 670.5 202.5 628.7 222.5 583.6 244.8
9 727.0 186.6 688.7 203.9 645.9 223.9 599.7 246.3
10 746.3 188.0 707.1 205.3 663.3 225.3 616.1 247.7
106
DCC065TR-10GPPY
5 692.2 198.7 654.9 217.7 612.9 239.4 567.9 263.5
6 712.2 200.2 673.6 219.2 630.4 240.9 584.1 265.1
7 732.4 201.7 692.5 220.7 648.2 242.5 600.6 266.7
8 752.7 203.3 711.7 222.3 666.1 244.1 617.4 268.3
9 773.1 204.9 731.0 223.9 684.3 245.7 634.4 269.9
10 793.7 206.5 750.5 225.6 702.7 247.4 651.7 271.6
107
DCC050DR-12EPV0
5 511.3 127.7 487.7 141.2 461.1 156.6 431.0 173.8
6 526.5 128.5 502.4 142.0 474.9 157.4 444.8 174.8
7 541.9 129.4 517.3 142.9 489.5 158.3 458.4 175.7
8 557.3 130.3 532.3 143.8 503.9 159.2 471.9 176.5
9 572.9 131.2 547.6 144.7 518.4 160.0 486.2 177.6
10 588.6 132.1 562.8 145.6 533.2 161.0 500.2 178.4
1 Output kW refers to the chilled water duty.
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
DCC Performance Data EC Fans
