AIREDALE DeltaChill - Page 118

Chillers
DeltaChill™ Air Cooled and FreeCool
118
Chiller Technical Manual 7267818 V1.13.0_01_2018
Technic al FreeCool
ELECTRICAL DATA 37 38 39
Unit Data DCF094TR-15HVWW DCF096TR-15HWWW DCF080TR-17GPYY
Nominal Run Amps (1) A 609.1 621.2 493.3
Maximum Start Amps A 872.5 856.6 756.7
Recommended Mains Fuse Size A 630 670 560
Evaporator
Immersion Heater Rating W 250 250 250
Condenser Fan - Per Fan (EC)
Quantity 15 15 17
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 55.2 / 59.2 / 59.2 59.2 / 59.2 / 59.2 59.2 / 47.9 / 47.9
Quantity 3 + 3 + 3 3 + 3 + 3 2 + 3 + 3
Motor Rating kW 33.1 / 36.2 / 36.2 36.2 / 36.2 / 36.2 36.2 / 29.8 / 29.8
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 298 / 298 298 / 298 / 298 298 / 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 568.4 582.1 469.7
Reactive power reduction/saving (4) kVAr 72.3 70.2 44.2
Maximum Start Amps A 831.8 817.5 733.1
Recommended Mains Fuse Size A 630 670 560
Electronic Soft-start
Nominal Run Amps A 609.1 621.2 493.3
Maximum Start Amps A 742.1 737.4 626.3
Recommended Mains Fuse A 630 670 560
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 568.4 582.1 469.7
Maximum Start Amps A 701.4 698.3 602.7
Recommended Mains Fuse Size A 630.0 670.0 560.0
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 35.0 28.5
Unit Nominal Run Amps A 637.4 656.0 521.5
Recommended Mains Fuse Size A 670 710 560
Motor Rating kW 16.4 20.3 16.4
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 35.0 41.5 35.0
Unit Nominal Run Amps A 643.9 662.4 528.0
Recommended Mains Fuse Size A 670 710 560
Motor Rating kW 20.3 23.9 20.3
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 33.2 26.9
Unit Nominal Run Amps A 630.6 647.9 515.3
Recommended Mains Fuse Size A 670 710 560
Motor Rating kW 16.8 20.7 16.8
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 33.2 39.2 33.2
Unit Nominal Run Amps A 635.7 652.8 520.5
Recommended Mains Fuse Size A 670 710 560
Motor Rating kW 20.7 24.4 20.7
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data - Regular Quiet
