AIREDALE DeltaChill - Page 175

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
175
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
152 153 154
DCC052DX-14EYY0 DCC054DX-13DYV0 DCC057DX-14DVV0
FreeCooling No No No
Enhance Capital Allowance No No No
Number of Refrigeration Circuits 2 2 2
Cooling Duty - EC Fans
Nominal Output - Mechanical (1) kW 512.4 532.3 559.7
Nominal Input - Mechanical kW 166.2 175.2 179.3
EER (2) 3.08 3.04 3.12
ESEER 4.26 4.38 4.41
Nominal Output - Free Cooling kW N/A N/A N/A
Ambient temperature for
100% Free Cooling
(5) °C N/A N/A N/A
Capacity Steps % 15-35-50-70-85-100 15-35-50-70-85-100 20-35-50-70-85-100
Minimum Turndown Ratio 0.17 0.17 0.18
Dimensions (H x W x L) mm 2682 x 2200 x 8242 2682 x 2200 x 8242 2682 x 2200 x 8242
Weight
Machine (3) kg 5590 5585 5650
Operating kg 5960 6015 6080
Water Volume (Total Internal) l 370 430 430
Maximum Waterow l/s 29.7 27.3 28.1
Minimum Waterow l/s 6.8 6.4 6.4
Face Area (Total) m² 2.38 2.38 2.38
Nominal Airow - EC Fans m³/s 61.8 57.4 61.8
Quantity 14 13 14
Maximum Speed - EC Fans rpm 725 725 725
Compressor Trio + Trio Trio + Trio Trio + Trio
Quantity of Compressors 6 6 6
Oil Charge Volume (Total) l 3 x 5.3 + 3 x 5.3 3 x 5.3 + 3 x 5.3 3 x 5.3 + 3 x 5.3
Refrigeration R410A / 2088
Charge (Total) kg 36 + 35 33 + 37 39 + 38
GWP Tonnes Equivalent CO2 tCO2 75 + 73 69 + 77 81 + 79
Refrigerant Control Electronic Expansion Valve (EEV)
Water Inlet / Outlet - Unit DN125 DN125 DN125
Water Drain / Bleed - Evap inch 1/2 1/2 1/2
Water System
Minimum System Water Volume (4) l 1543 1573 1702
Maximum System
Operating Pressure
Bar 10 10 10
DCC Mechanical Data - Extra Quiet
(1) Based on units performance at 12/7°C return/supply temperatures, 35°C ambient, 100% water. All performance data supplied in accordance with BBS EN14511-1:2013
(2) EER = DX Cooling Output / (Compressor input power + Fan Input Power),
(3) Based on standard unit without options, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options tted please refer to Airedale.
(4) For minimum system volume, refer to Design Features & Information - Minimum System Water Volume Calculations
(5) Ambient temperature that full Freecool capacity can be achieved
