AIREDALE DeltaChill - Page 179

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
179
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
164 165 166
DCC075TX-15GYYY DCC077TX-16GYYV DCC072TX-17GPYY
FreeCooling No No No
Enhance Capital Allowance No No No
Number of Refrigeration Circuits 3 3 3
Cooling Duty - EC Fans
Nominal Output - Mechanical (1) kW 738.0 760.2 709.1
Nominal Input - Mechanical kW 267.5 270.5 239.0
EER (2) 2.76 2.81 2.97
ESEER 4.19 4.20 4.29
Nominal Output - Free Cooling kW N/A N/A N/A
Ambient temperature for
100% Free Cooling
(5) °C N/A N/A N/A
Capacity Steps %
10-25-35-50-60-
70-80-90-100
10-25-35-45-60-
70-80-90-100
15-30-40-55-65-
80-90-100
Minimum Turndown Ratio 0.12 0.12 0.16
Dimensions (H x W x L) mm 2682 x 2200 x 9374 2682 x 2200 x 9374 2682 x 2200 x 10506
Weight
Machine (3) kg 6815 6900 7130
Operating kg 7415 7495 7825
Water Volume (Total Internal) l 600 595 695
Maximum Waterow l/s 46.1 46.1 47.5
Minimum Waterow l/s 17.7 17.7 10.5
Face Area (Total) m² 2.38 2.38 2.38
Nominal Airow - EC Fans m³/s 66.2 70.6 75.0
Quantity 15 16 17
Maximum Speed - EC Fans rpm 725 725 725
Compressor Trio + Trio + Trio Trio + Trio + Trio Tandem + Trio + Trio
Quantity of Compressors 9 9 8
Oil Charge Volume (Total) l
3 x 5.3 + 3 x 5.3
+ 3 x 5.3
3 x 5.3 + 3 x 5.3
+ 3 x 5.3
2 x 5.3 + 3 x 5.3
+ 3 x 5.3
Refrigeration R410A / 2088
Charge (Total) kg 31 + 33 + 33 30 + 33 + 37 28 + 34 + 35
GWP Tonnes Equivalent CO2 tCO2 65 + 69 + 69 63 + 69 + 77 58 + 71 + 73
Refrigerant Control Electronic Expansion Valve (EEV)
Water Inlet / Outlet - Unit DN125 DN125 DN150
Water Drain / Bleed - Evap inch 1/2 1/2 1/2
Water System
Minimum System Water Volume (4) l 1551 1551 1899
Maximum System
Operating Pressure
Bar 10 10 10
DCC Mechanical Data - Extra Quiet
(1) Based on units performance at 12/7°C return/supply temperatures, 35°C ambient, 100% water. All performance data supplied in accordance with BBS EN14511-1:2013
(2) EER = DX Cooling Output / (Compressor input power + Fan Input Power),
(3) Based on standard unit without options, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options tted please refer to Airedale.
(4) For minimum system volume, refer to Design Features & Information - Minimum System Water Volume Calculations
(5) Ambient temperature that full Freecool capacity can be achieved
