AIREDALE DeltaChill - Page 183

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
183
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
176 177 178
DCC080TX-19GYYV DCC081TX-22GYYV DCC082TX-20GYVV
FreeCooling No No No
Enhance Capital Allowance No No No
Number of Refrigeration Circuits 3 3 3
Cooling Duty - EC Fans
Nominal Output - Mechanical (1) kW 784.3 801.7 805.0
Nominal Input - Mechanical kW 260.6 254.2 264.3
EER (2) 3.01 3.15 3.05
ESEER 4.31 4.40 4.33
Nominal Output - Free Cooling kW N/A N/A N/A
Ambient temperature for
100% Free Cooling
(5) °C N/A N/A N/A
Capacity Steps %
10-25-35-45-60-
70-80-90-100
10-25-35-45-55-
70-80-90-100
10-25-35-45-60-
70-80-90-100
Minimum Turndown Ratio 0.12 0.11 0.11
Dimensions (H x W x L) mm 2682 x 2200 x 11638 2682 x 2200 x 12770 2682 x 2200 x 11638
Weight
Machine (3) kg 7680 8150 7760
Operating kg 8405 8920 8485
Water Volume (Total Internal) l 725 770 725
Maximum Waterow l/s 46.1 46.1 46.1
Minimum Waterow l/s 17.7 17.7 17.7
Face Area (Total) m² 2.38 2.38 2.38
Nominal Airow - EC Fans m³/s 83.9 97.1 88.3
Quantity 19 22 20
Maximum Speed - EC Fans rpm 725 725 725
Compressor Trio + Trio + Trio Trio + Trio + Trio Trio + Trio + Trio
Quantity of Compressors 9 9 9
Oil Charge Volume (Total) l
3 x 5.3 + 3 x 5.3
+ 3 x 5.3
3 x 5.3 + 3 x 5.3
+ 3 x 5.3
3 x 5.3 + 3 x 5.3
+ 3 x 5.3
Refrigeration R410A / 2088
Charge (Total) kg 34 + 35 + 41 37 + 38 + 45 34 + 39 + 41
GWP Tonnes Equivalent CO2 tCO2 71 + 73 + 86 77 + 79 + 94 71 + 81 + 86
Refrigerant Control Electronic Expansion Valve (EEV)
Water Inlet / Outlet - Unit DN150 DN150 DN150
Water Drain / Bleed - Evap inch 1/2 1/2 1/2
Water System
Minimum System Water Volume (4) l 1563 1572 1563
Maximum System
Operating Pressure
Bar 10 10 10
DCC Mechanical Data - Extra Quiet
(1) Based on units performance at 12/7°C return/supply temperatures, 35°C ambient, 100% water. All performance data supplied in accordance with BBS EN14511-1:2013
(2) EER = DX Cooling Output / (Compressor input power + Fan Input Power),
(3) Based on standard unit without options, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options tted please refer to Airedale.
(4) For minimum system volume, refer to Design Features & Information - Minimum System Water Volume Calculations
(5) Ambient temperature that full Freecool capacity can be achieved
