Unit waterside pressure drop based upon 100% water.
DCC Units with 100% Water
Waterow(l/s)
Unit
4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50
Pressure Drop (kPa)
79 DCF079TX-15GYYY 4.3 7.3 10.9 15.0 19.7 25.0 30.9 37.3 44.3 52.0 60.1 68.9 78.2 88.1 98.6 109.6 121.3 133.5 146.3 159.6 173.5 188.0 203.1 218.7
80 DCF082TX-16HYYV 3.6 6.0 8.9 12.3 16.1 20.3 25.1 30.2 35.9 42.0 48.5 55.5 63.0 70.9 79.2 88.0 97.3 107.0 117.2 127.8 138.9 150.4 162.4 174.8
81 DCF078TX-17GPYY 4.1 6.9 10.2 14.1 18.5 23.5 29.1 35.2 41.8 49.0 56.8 65.1 73.9 83.3 93.2 103.7 114.7 126.3 138.4 151.0 164.2 178.0 192.3 207.1
82 DCF082TX-18GYYY 4.0 6.7 9.9 13.7 18.1 22.9 28.3 34.3 40.8 47.8 55.4 63.5 72.1 81.2 90.9 101.2 111.9 123.2 135.1 147.5 160.4 173.8 187.8 202.3
83 DCF085TX-17HYVV 3.5 5.8 8.6 11.9 15.6 19.7 24.3 29.3 34.8 40.7 47.1 53.9 61.2 68.9 77.0 85.6 94.6 104.1 114.0 124.3 135.1 146.3 158.0 170.1
84 DCF089TX-18HVVV 3.5 5.9 8.7 12.0 15.7 19.9 24.6 29.6 35.2 41.2 47.6 54.5 61.8 69.6 77.9 86.6 95.7 105.3 115.3 125.8 136.7 148.1 159.9 172.2
85 DCF092TX-18HVVW 3.8 5.9 8.4 11.2 14.5 18.1 22.0 26.4 31.1 36.2 41.6 47.4 53.6 60.2 67.1 74.3 82.0 90.0 98.4 107.1 116.2 125.7 135.5 145.7
86 DCF094TX-18HVWW 3.8 5.9 8.4 11.2 14.5 18.1 22.0 26.4 31.1 36.2 41.6 47.4 53.6 60.1 67.1 74.3 82.0 90.0 98.4 107.1 116.2 125.7 135.5 145.7
87 DCF096TX-18HWWW 3.2 5.0 7.0 9.3 11.9 14.9 18.1 21.6 25.4 29.5 33.9 38.6 43.6 48.9 54.4 60.3 66.5 72.9 79.6 86.7 94.0 101.6 109.5 117.7
88 DCF074TX-19GPPY 3.8 6.4 9.5 13.1 17.2 21.8 26.8 32.4 38.5 45.0 52.1 59.6 67.6 76.2 85.2 94.7 104.7 115.2 126.2 137.7 149.6 162.1 175.0 188.5
89 DCF079TX-20GPYY 3.8 6.4 9.5 13.2 17.3 22.0 27.2 33.0 39.3 46.0 53.3 61.2 69.5 78.4 87.8 97.7 108.1 119.0 130.5 142.5 155.0 168.0 181.5 195.6
90 DCF085TX-19HYYV 3.3 5.5 8.2 11.2 14.7 18.7 23.0 27.8 33.0 38.7 44.8 51.2 58.2 65.5 73.3 81.4 90.0 99.1 108.5 118.4 128.7 139.4 150.6 162.2
91 DCF088TX-20HYVV 3.2 5.4 7.9 10.9 14.4 18.2 22.5 27.1 32.2 37.8 43.7 50.0 56.8 64.0 71.6 79.6 88.0 96.8 106.1 115.8 125.8 136.3 147.2 158.6
92 DCF084TX-21GYYY 3.7 6.3 9.3 12.9 17.1 21.7 26.8 32.5 38.7 45.4 52.6 60.4 68.6 77.4 86.7 96.5 106.8 117.6 129.0 140.8 153.2 166.1 179.5 193.4
93 DCF087TX-22HYYV 3.1 5.1 7.6 10.5 13.8 17.5 21.6
26.2 31.1 36.4 42.2 48.3 54.9 61.8 69.2 77.0 85.1 93.7 102.7 112.1 121.9 132.1 142.7 153.7
94 DCF092TX-21HVVV 3.5 5.5 7.8 10.5 13.5 16.9 20.6 24.6 29.1 33.8 38.9 44.4 50.2 56.3 62.8 69.7 76.9 84.4 92.3 100.5 109.1 118.0 127.3 136.9
95 DCF095TX-21HVVW 3.5 5.5 7.8 10.5 13.5 16.8 20.6 24.6 29.0 33.8 38.9 44.4 50.2 56.3 62.8 69.7 76.8 84.4 92.3 100.5 109.1 118.0 127.2 136.9
96 DCF097TX-21HVWW 3.5 5.5 7.8 10.5 13.5 16.8 20.6 24.6 29.0 33.8 38.9 44.4 50.2 56.3 62.8 69.6 76.8 84.4 92.3 100.5 109.0 118.0 127.2 136.8
97 DCF099TX-21HWWW 3.0 4.6 6.4 8.5 11.0 13.6 16.6 19.8 23.4 27.2 31.2 35.6 40.2 45.0 50.2 55.6 61.3 67.3 73.5 80.1 86.8 93.9 101.2 108.8
DCF Unit Pressure Drop
