1 Output kW refers to the chilled water duty (Based upon 20% Ethylene Glycol).
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
63 DCF065DX-12FWW0
6 650.9 179.4 612.6 198.1 571.3 219.1 527.0 242.6
7 668.9 180.9 629.6 199.7 587.1 220.8 541.5 244.3
8 687.1 182.5 646.7 201.3 603.0 222.4 556.2 246.0
10 724.1 185.8 681.5 204.7 635.5 225.9 586.3 249.5
12 761.6 189.3 716.9 208.2 668.7 229.5 617.1 253.2
14 799.8 192.9 753.0 211.9 702.5 233.3 648.6 257.1
64 DCF050DX-13DXY0
6 498.8 121.7 472.6 133.8 444.0 147.6 413.2 163.3
7 513.6 122.5 486.6 134.6 457.2 148.4 425.5 164.1
8 528.6 123.3 500.8 135.4 470.6 149.3 438.0 164.9
10 559.0 125.0 529.8 137.1 498.0 151.0 463.3 166.7
12 590.1 126.8 559.5 138.9 526.1 152.8 490.1 168.6
14 621.9 128.6 589.9 140.8 555.0 154.8 517.3 170.6
65 DCF053DX-13DPY0
6 517.9 125.2 490.4 137.7 460.4 151.9 428.2 168.0
7 533.1 126.0 504.8 138.5 474.0 152.8 440.9 168.8
8 548.5 126.9 519.4 139.4 487.8 153.7 453.7 169.7
10 579.8 128.7 549.2 141.2 515.9 155.5 480.0 171.6
12 611.8 130.7 579.7 143.2 544.8 157.5 507.1 173.6
14 644.6 132.7 610.9 145.2 574.3 159.5 534.9 175.6
66 DCF055DX-14DPV0
6 539.4 128.2 510.8 141.2 479.7 156.1 446.1 173.0
7 555.3 129.1 526.0 142.1 494.0 157.0 459.4 173.8
8 571.4 130.0 541.3 142.9 508.5 157.8 473.0 174.7
10 604.2 131.8 572.6 144.7 538.1 159.6 500.7 176.5
12 637.8 133.8 604.7 146.7 568.4 161.6 529.2 178.5
14 672.0 135.8 637.4 148.8 599.5 163.6 558.5 180.5
67 DCF057DX-13DYV0
6 567.8 145.3 537.1 160.3 503.8 177.3 467.7 196.3
7 584.3 146.4 552.8 161.3 518.5 178.3 481.4 197.4
8 601.0 147.4 568.7 162.4 533.4 179.4 495.3 198.5
10 635.1 149.7 601.0 164.7 563.9 181.7 523.7 200.8
12 669.8 152.0 634.1 167.1 595.1 184.1 553.0 203.3
14 705.3 154.5 667.9 169.6 627.0 186.7 583.0 205.8
68 DCF057DX-14DYY0
6 556.9 138.9 527.8 152.9 496.2 168.7 462.0 186.4
7 573.2 139.9 543.3 153.8 510.8 169.7 475.7 187.4
8 589.7 140.8 559.0 154.8 525.6 170.6 489.5 188.4
10 623.4 142.8 591.1 156.8 555.9 172.6 517.8 190.4
12 657.9 144.9 624.0 158.9 587.0 174.8 547.0 192.6
14 693.1 147.1 657.6 161.1 618.9 177.0 577.1 194.8
69 DCF060DX-14DVV0
6 589.7 148.0 558.1 163.4 523.5 181.1 486.1 200.9
7 607.0 149.0 574.5 164.5 539.0 182.1 500.5 202.0
8 624.5 150.1 591.2 165.5 554.7 183.2 515.2 203.1
10 660.2 152.3 625.1 167.7 586.7 185.4 545.1 205.3
12
696.6 154.6 659.8 170.1 619.6 187.8 575.9 207.7
14 733.6 157.1 695.2 172.6 653.1 190.3 607.4 210.3
DCF Performance Data EC Fans
