P374 Motor Current HMI Display Address 59
P375 Frequency At First Point For 5 Point VF 67
P376 Amplitude At First Point For 5 Point VF 67
P377 Frequency At Second Point For 5 Point
VF
68
P378 Amplitude At Second Point For 5 Point
VF
68
P379 Frequency At Third Point For 5 Point VF 68
P380 Amplitude At Third Point For 5 Point VF 68
P381 Frequency At Fourth Point For 5 Point VF 69
P382 Amplitude At Fourth Point For 5 Point VF 69
P383 Frequency At Fifth Point For 5 Point VF 69
P384 Amplitude At Fifth Point For 5 Point VF 69
P385 Deceleration Process Enable 128
P386 Deceleration Time 1 128
P387 Deceleration Frequency 1 128
P388 Deceleration Time 2 128
P389 Deceleration Frequency 2 129
P390 Deceleration Time 3 129
P391 Deceleration Frequency 3 129
P392 Deceleration Time 4 129
P393 Flying Start Compensation Enable 114
P394 Flying Start Compensation Current
Threshold
114
P395 Flying Start Compensation Frequency
Reduce Speed
115
P396 Deceleration Control Enable 133
P397 DC Bus Lower Limit 134
P398 DC Bus Upper Limit 134
P399 Deceleration Time 59
P401 Acceleration Time 60
P402 Acceleration Ramp Transition Time 60
P403 Acceleration Time Unit 60
P405 Deceleration Ramp Transition Time 60
P406 Deceleration Time Unit 61
P408 Flying Start Compensation Defer Restore
Voltage Speed Current Threshold
115
P409 Amplification Coefficient Of Error Terms 61
P410 Flying Start Compensation Current
Threshold for Fast Compensation
115
P411 Over Speed Upper Limit Reference 151
P412 Over Speed Lower Limit Reference 151
P413 Frequency Command Lower Limit 61
P414 Frequency Command Deadband Upper
Limit
61
P415 Frequency Command Upper Limit 62
No. Parameter Name Page
P416 Flying Start Mode 115
P417 Flying Start Motor Speed Search
Timeout
116
P418 Acceleration Time 1 130
P419 Acceleration Frequency 1 130
P420 Acceleration Time 2 130
P421 Acceleration Frequency 2 130
P422 Acceleration Time 3 131
P423 Acceleration Frequency 3 131
P424 Acceleration Time 4 131
P425 Acceleration Process Enable 131
P434 Deceleration Iq Threshold 134
P435 Deceleration Control Frequency Range 134
P436 Current Limitation Enable 109
P438 Current Limitation Enable Frequency
Range Lower Limit
109
P441 Current Limitation Threshold 109
P442 Current Limitation Heating Time 110
P443 Current Limitation Cooling Time 110
P444 Current Limitation Decel Ramp Slope
Change
110
P445 Current Limitation Cycle Load Control
Enable
110
P447 Minimum Start Frequency During Time 127
P448 Minimum Start Frequency 127
P449 Low Speed Voltage Compensation
During Flux Building Process
127
P451 Low Speed Voltage Compensation 70
P452 Low Speed Voltage Compensation
Frequency Threshold
70
P453 V/F Curve 70
P454 Flux Time 70
P455 Modulation Index 71
P456 Motor Voltage Upper Limit 71
P457 Flying Start Voltage Recovery Time (Low
Speed Region)
116
P458 Coefficient A 71
P459 Flying Start Voltage Recovery Time
(High Speed Region)
116
P460 Rated Output Frequency 62
P461 Restart Enable 125
P462 Fault Reset Timeout 125
P463 Flying Start Low/High Speed Regions
Boundary
116
P465 Power Cell Fault Auto Reset Delay 125
P466 Maximum Output Frequency 62
P467 Over Speed Enable 62
