CHAPTER 5 REFERENCE GUIDE
EFD1000/500 MFD Pilot’s Guide
Page 5-50 091-00006-001 REV B
EFD1000/500 MFD Pilot’s Guide
Page 5-51091-00006-001 REV B
5.2.9.4. Descriptive Messages
Two types of descriptive messages may be displayed, operational and error messages.
Only one message will display at a time, with error messages taking precedence over
operational messages. Error messages are displayed when the XM receiver becomes
non-operational. Operational Messages are described in Table 5-14 and Error Messages
are described in Table 5-15. Each table lists the messages in order of precedence.
Message Description Message
Loading Upon initialization, when
the XM receiver becomes
operational, the Loading
operational message displays
in the XM Receiver Status page.
The XM receiver is now
operational, but may
take several minutes
before data products are
displayed.
Geo Limit If XM data is not available for
the current position, the Geo
Limit operational message
displays on all selected Data
Link Weather pages.
Geographic limitation:
XM Weather is not
available
Winds Aloft If a range above 500 nm is
selected for the Winds Aloft
product page, the XM Status
Overlay displays with the
Winds Aloft message.
Winds Aloft data removed
for ranges > 500nm
Table 5-14 XM Status Operational Messages
