Aspen Avionics Evolution EFD 1000 MFD - Figure 3-4 Thumbnail Screen LAYOUT; Table 3-1 EFD1000;500 MFD Display Components

CHAPTER 3 DISPLAY &CONTROLS
EFD1000/500 MFD Pilot’s Guide
Page 3-2 091-00006-001 REV B
EFD1000/500 MFD Pilot’s Guide
Page 3-3091-00006-001 REV B
Figure 3-4 Thumbnail Screen LAYOUT
20 Lower Split Screen Window
21 Upper Left Thumbnail Window
22 Upper Right Thumbnail Window
23 Lower Thumbnail Window
24 VIEW Name
25 Heading / Strikes VIEW Mode
26 Terrain AGL, Trac lter, Strikes Rate
27 Right Knob Label
28 Right Knob Status
29 Select Weather Label (Weather VIEW only)
30 Trac Advisory Notication
31 Display Info Label (Nav Map & Weather only)
32 Left Knob Label
33 Left Knob Status
34 Map Range and Declutter Level
35 Annunciations
36 Airspeed (Secondary AI only)
37 Altitutde (Secondary AI only)
Table 3-1 EFD1000/500 MFD Display Components
