CHAPTER 3 DISPLAY &CONTROLS
EFD1000/500 MFD Pilot’s Guide
Page 3-8 091-00006-001 REV B
EFD1000/500 MFD Pilot’s Guide
Page 3-9091-00006-001 REV B
When the INFO button is pressed rotating the Left Knob selects dierent objects on the
Navigation Map (Airports/VORs) or METAR, AIRMET/SIGMET, and TFR weather pages.
Pressing the Left Knob after the INFO button has been pressed will display the selected
object’s textual information, when available.
3.2.1.2 Left Button
The Left Button displays the label Select when the AIRMET/SIGMET, METAR, or TFR
Weather view is displayed. Pressing the Left Button activates alert selection, and then
rotating the Left Knob selects individual alerts. See Section 5.2. Data Link Weather for
more information.
3.2.1.3. Middle Button
The Middle Button is used to select a navigation source for the Secondary HSI when
the HSI VIEW has the FOCUS (EFD1000 MFD only). A navigation source label (e.g. GPS1,
VLOC1) will display directly above the button when its functionality is available. During
a trac alert, pressing the Middle Button will display the Trac VIEW; and when pressed
a second time the display returns to the previous VIEW. See Section 5.4.2. Secondary
Horizontal Situation Indicator (HSI) and Section 5.3.2. Trac for more information.
3.2.1.4. Right Button
When the Data Link Weather VIEW is displayed and has the FOCUS, the Right Button
displays the label Sel WX. Pressing the lower Right Button activates Weather Product
Selection, and then rotating the Right Knob selects dierent Weather Products. See
Section 5.2. Data Link Weather for more information.
