5.3.3.1. WX-500 Annunciations
WX-500 data is removed from the display, the rate annunciation displays with a
horizontal red line, and the ownship symbol is removed from the display when any of
the following situations occur (Table 5-23).
Error Message Explanation
TEST INIT
Sensor is in self-test mode.
FAIL
Sensor status is an unrecoverable fault or undened.
TEST INIT FAIL
Self Test report not received in 10 seconds.
ERROR
Undened recoverable error.
ERROR
ANT ERR
Recoverable antenna error.
ERROR
MIC INHIBIT STUCK
Recoverable inhibit line stuck error.
ERROR
ANT JMP CHG
Recoverable Antenna Jumper Changed error.
FAIL
HDG INVALID
Heading information is unavailable or invalid
FAIL
NO LINK
Congured but data is not detected.
Table 5-23 WX-500 Annunciations
