Aspen Avionics Evolution EFD 1000 MFD - Specifications; EFD Display Unit; Table 7-2 EFD1000 Display Unit Specifications

CHAPTER 7 APPENDICES
EFD1000/500 MFD Pilot’s Guide
Page 7-4
091-00006-001 REV B
Input Voltage +8 to +32 Volts DC
Max Current 2.4 Amps @ 28 VDC
4.8 Amps @ 14 VDC
I/O SPECIFICATIONS:
ARINC 429 Inputs 5
ARINC 429 Outputs 1
RS-232 Inputs 5
RS-232 Outputs 3
Pitot / Static Quick Connect
CERTIFICATION SPECIFICATIONS:
Technical Standard
Order
TSO-C2d Airspeed Instruments
1
TSO-C3d Turn and Slip Instrument
1
TSO-C4c Bank and Pitch Instruments
1
TSO-C6d Direction Instrument Magnetic
(Gyroscopically Stabilized)
1
TSO-C8d Vertical Velocity Instrument
(Rate of Climb)
1
TSO-C10b Altitude Pressure Activated Sensitive Type
1
TSO-C106 Air Data Computer
1
TSO-C113 Airborne Multipurpose Electronic Displays
Software RTCA DO-178B Level C
Environmental RTCA DO-160E
Categories See Environmental Qualication Sheet found in the
installation manual.
Table 7-2 EFD1000 Display Unit Specications
7.3. Specications
7.3.1. EFD Display Unit
GENERAL SPECIFICATIONS:
Width 3.50 in. (Measured at Bezel)
Height 7.00 in. (Measured at Bezel)
Can Depth 4.15 in. (Rear of Bezel to Rear of Can)
Overall Depth 6.35 in. (Knob to Rear Pressure Fitting)
Weight EFD1000 2.9 lbs (with Mounting Bracket)
EFD500 2.6 lbs (with Mounting Bracket)
Display Type 6.0 in. Diagonal TFT Active Matrix LCD (400x760)
Display Colors 32,768
Face Anti-Reective Coated Glass
Backlight High Intensity White LED
Rotary Knobs Optical Encoder with Momentary Push
Dimming Manual & Automatic (Front Bezel Mounted Sensor)
OPERATIONAL SPECIFICATIONS:
Operating Temp -20°C to +55°C
Storage Temp -55°C to +85°C
Max Un-Pressurized
Operating Altitude
35,000 ft
Max Pressurized
Operating Altitude
55,000 ft
Cooling Integral Fan
Max Humidity 95% at 50°C
1. EFD1000 MFD Only.
