CHAPTER 5 REFERENCE GUIDE
EFD1000/500 MFD Pilot’s Guide
Page 5-2 091-00006-001 REV B
EFD1000/500 MFD Pilot’s Guide
Page 5-3091-00006-001 REV B
NOTE
Terrain and NEXRAD are mutually exclusive. The
Navigation map will only display one of these overlays
at a time. Turning on the terrain overlay will remove
NEXRAD information, and conversely turning on
NEXRAD will remove Terrain information.
NOTE
When the ARC compass mode is selected the Ownship
symbol is located at the bottom 1/3 of the VIEW.
The Range +/- button and the Map Hot Key allow the pilot to control the map range
1
and provide feature declutter. The current map range and declutter settings are
shown in the lower left corner of the VIEW. Additionally, more detailed customization
is available from the main menu, giving the pilot control over the symbols that can be
shown on the map:
• Airports
• Hydrographic Features
2
• Cultural Boundaries
2
• Highways
• Airspace Boundaries
2
1. The map range scale settings are 0.5, 1, 2, 3, 5, 10, 15, 20, 30, 40, 60, 80, 100, 200, 500,
1000 and 2000 nautical miles from the ownship position to the range ring.
2. Based on map range and declutter settings, see Table 5-6.
