User's Manual 14. Network
Parameter Description
used as the interface to the WAN, then you need to define NAT rules
(using the NATTranslation parameter) to translate the VoIP LAN IP
addresses (defined in the Multiple Interface table and associated with
SIP and media interfaces) into global, public IP addresses.
 This parameter is applicable only if the data-routing functionality is
supported (i.e., relevant Software License Key is installed on the
device).
14.1.1 Assigning NTP Services to Application Types
You can associate the Network Time Protocol (NTP) application with the OAMP or Control
application type. This is done using the EnableNTPasOAM ini file parameter.
14.1.2 Multiple Interface Table Configuration Rules
The Multiple Interface table configuration must adhere to the following rules:

Multiple Control and Media interfaces can be configured with overlapping IP
addresses and subnets.

The prefix length replaces the dotted-decimal subnet mask presentation and must
have a value of 0-30 for IPv4 addresses.

Only one OAMP interface must be configured and this must be an IPv4 address. This
OAMP interface can be combined with Media and Control.

At least one Control interface must be configured with an IPv4 address.

At least one Media interface must be configured with an IPv4 address.

The network interface types can be combined:
• Example 1: One combined OAMP-Media-Control interface with an IPv4 address
• Example 2:
♦ One OAMP interface with an IPv4 address
♦ One or more Control interfaces with IPv4 addresses
♦ One or more Media interfaces with IPv4 interfaces
• Example 3:
♦ One combined OAMP-Media interface with an IPv4 address
♦ One or more combined Media-Control interfaces with IPv4 addresses.

Each network interface can be configured with a Default Gateway. The address of the
Default Gateway must be in the same subnet as the associated interface. Additional
static routing rules can be configured in the IP Routing table.

The interface name must be configured (mandatory) and unique for each interface,
and can include up to 16 characters.

For IPv4 addresses, the 'Interface Mode' column must be set to IPv4 Manual (numeric
value 10).

For network configuration to take effect, you must save the configuration to the
device's flash memory (burn) with a device reset.
