66.11.5.7 Three-Way Conferencing Parameters
The three-way conferencing parameters are described in the table below.
Three-Way Conferencing Parameters
Parameter Description
Web: Enable 3-Way
Conference
EMS: Enable 3 Way
CLI: enable-3w-conf
[Enable3WayConferenc
e]
Enables the 3-Way Conference feature.
 [0] Disable (default)
 [1] Enable
Note: For this parameter to take effect, a device reset is required.
Web: Three Way
Conference Mode
EMS: 3 Way Mode
CLI: 3w-conf-mode
[3WayConferenceMode]
Determines the mode of operation when the 3-Way Conference feature
is used.
 [0] AudioCodes Media Server = (Default) The Conference-initiating
INVITE (sent by the device) uses the ConferenceID concatenated
with a unique identifier as the Request-URI. This same Request-URI
is set as the Refer-
To header value in the REFER messages that are
sent to the two remote parties. This conference mode is used when
operating with AudioCodes IPMedia conferencing server.
 [1] Non-AudioCodes Media Server = The Conference-initiating
INVITE (sent by the device) uses only the ConferenceID as the
Request-URI. The conference server sets the Contact header of the
200 OK response to the actual unique identifier (Conference URI) to
be used by the participants. This Conference URI is then included
(by the device) in the Refer-To header value in the REFER
messages sent by the device to the remote parties. The remote
parties join the conference by sending INVITE messages to the
conference using this conference URI.
 [2] On Board = On-board, three-way conference. The conference is
established on the device without the need of an external
Conference server. You can limit the number of simultaneous, on-
board 3-way conference calls, by using the
MaxInBoardConferenceCalls parameter.
Notes:
 This parameter is applicable only to FXS and BRI interfaces.
 Three-way conferencing using an external conference server is
supported only by FXS interfaces.
 When using an external conference server (options [0] or [1]), a
conference call with up to six participants can be established.
Web: Max 3 Way
Conference
EMS: Max In Board Calls
[MaxInBoardConference
Calls]
Defines the maximum number of simultaneous, on-board three-way
conference calls.
The valid range is 0 to 5. The default is 2.
Notes:
 For enabling on-board, three-way conferencing, use the
3WayConferenceMode parameter.
 This parameter is applicable only to FXS and BRI interfaces.
