3.6 Configuring Virtual Routing and Forwarding
The Virtual Routing and Forwarding (VRF) Lite feature enables the ability to use a single
physical router as several logical routers. Each VRF is associated with its own routing
table. To create fully separated logical routers on the same physical router, every interface
can be mapped to a specified VRF and static routes can be added to it.
For VRF configuration, refer to the MSBR Series CLI Reference Guide for Data
Functionality.
3.7 Enabling Remote HTTP/S Web Management
To access the Web interface remotely through the WAN port using HTTP or HTTPS, you
need to enable remote management as described in the procedure below.
To define WAN HTTP/S port for remote Web management:
1. Open the WEB Security Settings page (Configuration tab > System menu >
Management submenu > WEB Security Settings).
Figure 3-21: Defining WAN HTTP Port
2. From the 'WAN OAMP Interface' drop-down list, select the WAN interface.
3. From the ‘Allow WAN access to HTTPS’ drop-down list, select Enable.
4. Click Submit.
3.8 Reset the Device and Reconnect with WAN
When you have completed all the procedures described in the previous sections, you need
to reset the device to apply your changes. Once the settings are applied, you can access
the device's management interface through the WAN IP address.
