Version 6.6 697 Mediant 800 MSBR
User's Manual 58. Data Status
58.4 Viewing QoS Queues Statistics
You can view an accurate, real-time information on the traffic moving through your defined
device classes. For example, the amount of packets sent, dropped or delayed are just a
few of the parameters that you can monitor per shaping class.
To view your class statistics:
Click the QoS Class Statistics item (Status & Diagnostics tab > Data Status menu
> QoS Queues Statistics); the following page appears:
Figure 58-5: QoS Queues Statistics Page
Note: Class statistics are only available after defining at least one class; otherwise,
the page does not display any information.
58.5 Viewing Logged Data Events
The Data Log item displays a list of recent events occurred on the device.
To view logged messages:
Click the Data Log item (Status & Diagnostics tab > Data Status menu > Data
Log); the following page appears:
Figure 58-6: System Log Page
