User's Manual 25. Manipulation
These two numbers can be manipulated by entering the following special strings in the
'Destination Prefix' field of the Redirect Number Tel -> IP manipulation table:

"RN" - used in the rule to manipulate the Redirected number (i.e., originally called
number or Diverting number).

"DN" - used in the rule to manipulate the Diverted-to number (i.e., the new called
number or destination). This manipulation is done on the user part in the Contact
header of the SIP 302 response.
For example, assume the following required manipulation:

Manipulate Redirected number 6001 (originally called number) to 6005

Manipulate Diverted-to number 8002 (the new called number or destination) to 8005
The configuration in the Redirect Number Tel -> IP manipulation table is as follows:
Redirect Number Configuration Example
Parameter Rule 1 Rule 2
Destination Prefix
RN DN
Redirect Prefix
6 8
Stripped Digits From Right
1 1
Suffix to Add
5 5
Number of Digits to Leave
5 -
After the above manipulation is done, the device sends the following outgoing SIP 302
response:
SIP/2.0 302 Moved Temporarily
Via: SIP/2.0/TLS 10.33.45.68;branch=z9hG4bKac54132643;alias
From: "MP118 1" <sip:8001@10.33.45.68>;tag=1c54119560
To: <sip:6001@10.33.45.69;user=phone>;tag=1c664560944
Call-ID: 541189832710201115142@10.33.45.68
CSeq: 1 INVITE
Contact: <sip:8005@10.33.45.68;user=phone>
Supported: em,timer,replaces,path,early-session,resource-priority
Allow:
REGISTER,OPTIONS,INVITE,ACK,CANCEL,BYE,NOTIFY,PRACK,REFER,INFO,SUB
SCRIBE,UPDATE
Diversion: <tel:6005>;reason=unknown;counter=1
Server: Audiocodes-Sip-Gateway-IPmedia 260_UN/v.6.20A.043.001
Reason: SIP ;cause=302 ;text="302 Moved Temporarily"
Content-Length: 0
25.7 Mapping NPI/TON to SIP Phone-Context
The Phone-Context table page allows you to map Numbering Plan Indication (NPI) and
Type of Number (TON) to the SIP 'phone-context' parameter. The 'phone-context'
parameter appears in the standard SIP headers where a phone number is used (i.e.,
Request-URI, To, From, and Diversion). When a call is received from the ISDN/Tel side,
the NPI and TON are compared against the table and the matching 'phone-context' value is
used in the outgoing SIP INVITE message. The same mapping occurs when an INVITE
with a 'phone-context' parameter is received.
