5.1.10 Logging Off the Web Interface
The procedure below describes how to log off the Web interface.
To log off the Web interface:
1. On the toolbar, click the Log Off icon; the following confirmation message box
appears:
Figure 5-18: Log Off Confirmation Box
2. Click OK; you are logged off the Web session and the Web Login dialog box appears
enabling you to re-login, if required.
5.2 Viewing the Home Page
The Home page is displayed when you access the device's Web interface. The Home page
provides you with a graphical display of the device's front panel, showing color-coded
status icons for various operations device.
To access the Home page:
On the toolbar, click the Home icon.
Figure 5-19: Home Page
Note: The displayed number and type of telephony interfaces, LAN interfaces and
WAN interfaces depends on the ordered hardware configuration.
