Figure 3-2: Defining LAN Data Routing IP Address
5. Click OK to save your settings.
3.2 Configuring Device's DHCP Server
The device is supplied with an enabled embedded DHCP server for the LAN, and with
default IP pool addresses relating to the default subnet LAN. You can either disable the
DHCP server or modify the IP address pool accordingly. The device's DHCP server uses
this setting to allocate IP addresses to the computers connected to its LAN interface.
To configure DHCP on the device:
1. Open the DHCP Server page (Configuration tab > Data menu > Data Services >
DHCP Server).
2. Click the Edit button corresponding to the "LAN switch VLAN 1" connection.
3. From the 'IP Address Distribution' drop-down list, select DHCP Server.
4. Define the IP address pool.
Figure 3-3: Configuring the DHCP Server
5. Click OK.
