Figure 47-52: IPSec Shared Secret Key
5. Enter the IPSec shared secret, which is the encryption key jointly decided upon with
the network you are trying to access, and then click Next; the following is displayed if
successfully configured:
Figure 47-53: IPSec Connection Added Successfully
6. Select the 'Edit the Newly Created Connection' check box if you want to edit the new
connection after clicking Finish.
7. Click Finish to save the settings; the new IPSec Server is added to the network
connections list.
47.11 General Routing Encapsulation (GRE)
The device allows you to create a GRE tunnel to transport multicast traffic and IPv6, in
addition to other existing tunneling capabilities such as L2TP.
To create a new GRE tunnel:
1. In the Connections page, click the New icon; the Connection Wizard opens.
2. Select the Advanced Connection option, and then click Next; the Advanced
Connection page appears.
3. Select the General Routing Encapsulation (GRE) option, and then click Next; the
following page appears.
Figure 47-54: Configuring General IPIP Parameters
4. In the 'Remote Endpoint IP Address' field, enter the tunnel's remote endpoint IP
address.
5. In the 'Local Interface IP Address' field, enter the local IP address for the interface.
6. In the 'Remote Network IP Address' and 'Remote Subnet Address fields, enter the IP
address and subnet mask (respectively) of the remote network that is to be accessed
via the tunnel, and then click Next; the following GRE connection message is
displayed if successfully configured:
