AudioCodes Media 800 MSBR

Version 6.6 477 Mediant 800 MSBR
User's Manual 31. SBC Configuration
Contact: <sip:7000@212.179.1.12>
Supported: em,100rel,timer,replaces
Allow:
REGISTER,OPTIONS,INVITE,ACK,CANCEL,BYE,NOTIFY,PRACK,REFER
User-Agent: Sip Message Generator V1.0.0.5
Content-Type: application/sdp
Content-Length: 155
v=0
o=SMG 5 9 IN IP4 212.179.1.11
s=Phone-Call
c=IN IP4 212.179.1.11
t=0 0
m=audio 8000 RTP/AVP 8
a=rtpmap:8 pcma/8000
a=sendrecv
a=ptime:20
The SIP message manipulations in the example above (contributing to typical topology
hiding) are as follows:

Inbound source SIP URI user name from "7000" to "97000":
From:<sip:7000@10.2.2.6;user=phone;x=y;z=a>;tag=OlLAN;paramer1
=abe
to
From:
<sip:97000@IP_PBX;user=phone;x=y;z=a>;tag=OWan;paramer1=abe

Source IP Group name (i.e., SIP URI host name) from "10.2.2.6" to "IP_PBX":
From:<sip:7000@10.2.2.6;user=phone;x=y;z=a>;tag=OlLAN;paramer1
=abe
to
From:
<sip:97000@IP_PBX;user=phone;x=y;z=a>;tag=OWan;paramer1=abe

Inbound destination SIP URI user name from "1000" to 9721000":
INVITE sip:1000@10.2.2.3;user=phone;x=y;z=a SIP/2.0
To: <sip:1000@10.2.2.3;user=phone>
to
INVITE sip:9721000@ITSP;user=phone;x=y;z=a SIP/2.0
To: <sip:9721000@ITSP;user=phone>

Destination IP Group name (SIP URI host name) from "10.2.2.3" to "ITSP":
INVITE sip:1000@10.2.2.3;user=phone;x=y;z=a SIP/2.0
To: <sip:1000@10.2.2.3;user=phone>
to
INVITE sip:9721000@ITSP;user=phone;x=y;z=a SIP/2.0
To: <sip:9721000@ITSP;user=phone>
31.5.1 Configuring IP-to-IP Inbound Manipulations
The IP to IP Inbound Manipulation table allows you to configure up to 100 manipulation
rules for manipulating the source or destination SIP URI user part of inbound SIP dialog
requests. You can apply these manipulations to different SIP dialog message types (e.g.,
INVITE or REGISTER) and SIP headers as follows:

Manipulated destination URI user part are done on the following SIP headers:
Request-URI, To, and Remote-Party-ID (if exists)
