AudioCodes Media 800 MSBR

Version 6.6 995 Mediant 800 MSBR
User's Manual 68. Technical Specifications
68 Technical Specifications
The device's technical specifications are listed in the table below.
Notes:
• All specifications in this document are subject to change without prior
notice.
• The compliance and regulatory information can be downloaded from
AudioCodes Web site at http://www.audiocodes.com/library.
Technical Specifications
Function Specification
Capacity
SBC Sessions
 RTP-RTP: 60
 SRTP-RTP: 60
IP-to-IP Transcoding
Sessions
30
Registered Users
(SAS/SBC/CRP/)
200
Telephony Interfaces
PRI Interfaces
Single E1/T1 span, using RJ-48c ports
BRI Interfaces
Up to 8 BRI ports (16 calls), network S/T interfaces - NT or TE termination
Analog Interfaces
 Up to 12 FXS, using RJ-11 ports
 Up to FXO ports, using RJ-11 ports
 (Option) 1 FXS Lifeline ports in case of power failure
 FXS Loop Impedance - Up to 1,600 Ohms
Networking Interfaces
WAN
 Copper 1000Base-T (Gigabit Ethernet) using RJ-45 port
 SHDSL using RJ-11 ports
 ADSL2+/VDSL2 using RJ-11 ports
 3G Cellular (primary or backup) using USB modem
LAN
 4 Gigabit Ethernet (10/100/1000Base-T) using RJ-45 ports
 8 Fast Ethernet (FE) 10/100Base-TX ports using RJ-45 ports
 Power-over-Ethernet (PoE) on all ports is optional, compliant to 802.3af-
2003 with auto-detection, supporting up to 15.4W per port respectively.
PoE management
Wi-Fi
 Wireless LAN 802.11 b/g/n access point at 2.4 and 5 GHz, integrated 2
Tx and 2 Rx, enabling data rates of up to 300 Mbps
 2 Wi-Fi antennas
USB
1 USB port for optional, 3G cellular WAN modem and/or USB storage
services
Media Processing
Voice Coders
G.711, G.722, G.723.1, G.726, G.729A, and AMR-WB (G.722.2)
