To configure SBC call testing:
1. Configure the test call parameters:
a. Open the Test Call Settings page (Configuration tab > System menu > Test
Call > Test Call Settings).
Figure 63-7: Test Call Settings Page
b. In the 'Test Call ID' field, enter a prefix number for the simulated test endpoint on
the device.
c. In the 'SBC Test ID' field, enter a called prefix number for identifying the call as
an SBC test call.
d. Click Submit to apply your settings.
2. Configure regular SBC call processing rules for called number prefix "101", such as
classification and IP-to-IP routing through a proxy server.
Notes:
• For a full description of this parameter, see 'SIP Test Call Parameters' on
page 773.
• This test call is initiated only upon receipt of incoming calls and with the
configured prefix.
• This call test is done on all SIP interfaces.
• This test call is applicable only to the SBC application.
63.5 Test Call Configuration Examples
Below are a few examples of test call configurations.
Single Test Call Scenario: This example describes the configuration of a simple test
call scenario that includes a single test call between a simulated test endpoint on the
device and a remote endpoint.
Figure 63-8: Single Test Call Example
• Test Call table configuration:
♦ Endpoint URI: "101"
♦ Called URI: "201"
♦ Route By: Dest Address
