2. Select the check box corresponding to the SNMP Trusted Manager that you want to
enable and for whom you want to define an IP address.
3. Define an IP address in dotted-decimal notation.
4. Click Submit to apply your changes.
5. To save the changes, see 'Saving Configuration' on page 624.
7.4 Configuring SNMP V3 Users
The SNMP v3 Users page allows you to configure authentication and privacy for up to 10
SNMP v3 users.
To configure SNMP v3 users:
1. Open the SNMP v3 Users page (Configuration tab > System menu > Management
submenu > SNMP submenu > SNMP V3 Users).
2. Click Add; the following dialog box appears:
Figure 7-4: SNMP V3 Setting Page - Add Record Dialog Box
3. Configure the SNMP V3 Setting parameters according to the table below.
4. Click Submit to apply your settings.
5. To save the changes, see 'Saving Configuration' on page 624.
Notes:
• If you delete a user that is associated with a trap destination (in
'Configuring SNMP Trap Destinations' on page 82), the configured trap
destination becomes disabled and the trap user reverts to default (i.e.,
SNMPv2).
• The SNMP v3 Users table can also be configured using the table ini file
parameter, SNMPUsers (see 'SNMP Parameters' on page 766) or CLI
command, configure system > snmp v3-users.
