Version 6.6 339 Mediant 800 MSBR
User's Manual 26. Routing
Parameter Description
Operation (Destination)
Web: Trunk Group ID
CLI: trunk-group-id
[TrunkGroupId]
For IP-to-Tel calls: Defines the Trunk Group to where the incoming SIP
call is sent.
For IP-to-IP calls: Identifies the call as an IP-to-
IP call if this parameter is
set to -1.
Web: Trunk ID
CLI: trunk-id
[TrunkId]
Defines the Trunk to where the incoming SIP call is sent.
Notes:
If both 'Trunk Group ID' and 'Trunk ID' parameters are configured in
the table, the routing is done according to the 'Trunk Group ID'
parameter.
The method for selecting the trunk's channel to which the IP call is
sent is configured by the global parameter, ChannelSelectMode.
Currently, this field can only be configured using the ini file.
Web: IP Profile ID
CLI: ip-profile-id
[ProfileId]
Assigns an IP Profile (configured in 'Configuring IP Profiles' on page
245) to the call.
Web: Source IP Group
ID
CLI: src-ip-group-id
[SrcIPGroupID]
For IP-to-Tel calls:
Defines the IP Group associated with the incoming IP
call. This is the IP Group that sent the INVITE message. This IP Group
can later be used as the 'Serving IP Group' in the Account table for
obtaining authentication user name/password for this call (see
'Configuring Account Table' on page
225).
For IP-to-IP calls: Assigns the IP Group to the incoming IP call. This IP
Group can later be used for outbound IP routing and as the 'Serving IP
Group' in the Account table for obtaining authentication user
name/password for this call (see Configuring Account Table on page
225).
