AudioCodes Media 800 MSBR

Version 6.6 483 Mediant 800 MSBR
User's Manual 31. SBC Configuration
Parameter Description

This parameter functions together with the 'Call Trigger' parameter
(see below).
 For more information on interworking of SIP 3xx redirect responses or
REFER messages, see 'Interworking SIP 3xx Redirect Responses' on
page 442 and 'Interworking SIP REFER Messages' on page 445,
respectively.
Call Trigger
CLI: trigger
[IPOutboundManipulati
on_Trigger]
Defines the reason (i.e, trigger) for the re-routing of the SIP request:
 [0] Any = (Default) Re-routed for all scenarios (re-routes and non-re-
routes).
 [1] 3xx = Re-routed if it triggered as a result of a SIP 3xx response.
 [2] REFER = Re-routed if it triggered as a result of a REFER request.
 [3] 3xx or REFER = Applies to options [1] and [2].
 4] Initial only = Regular requests that the device forwards to a
destination. In other words, re-routing of requests triggered by the
receipt of REFER or 3xx does not apply.
Manipulated URI
CLI: manipulated-uri
[IPOutboundManipulati
on_IsAdditionalManipu
lation]
Determines whether the source or destination SIP URI user part is
manipulated.
 [0] Source = (Default) Manipulation is done on the source SIP URI
user part.
 [1] Destination = Manipulation is done on the destination SIP URI
user part.
Operation Manipulation Rule (Action)
Remove From Left
CLI: remove-from-left
[IPOutboundManipulati
on_RemoveFromLeft]
Defines the number of digits to remove from the left of the user name
prefix. For example, if you enter 3 and the user name is "john", the new
user name is "n".
Remove From Right
CLI: remove-from-right
[IPOutboundManipulati
on_RemoveFromRight]
Defines the number of digits to remove from the right of the user name
prefix. For example, if you enter 3 and the user name is "john", the new
user name is "j".
Leave From Right
CLI: leave-from-right
[IPOutboundManipulati
on_LeaveFromRight]
Defines the number of characters that you want retained from the right of
the user name.
Prefix to Add
CLI: prefix-to-add
[IPOutboundManipulati
on_Prefix2Add]
Defines the number or string that you want added to the front of the user
name. For example, if you enter 'user' and the user name is "john", the
new user name is "userjohn".
Suffix to Add
CLI: suffix-to-add
[IPOutboundManipulati
on_Suffix2Add]
Defines the number or string that you want added to the end of the user
name. For example, if you enter '01' and the user name is "john", the
new user name is "john01".
Privacy Restriction Mode
CLI: privacy-restriction-
mode
[IPOutboundManipulati
on_PrivacyRestriction
Mode]
Determines user privacy handling (i.e., restricting source user identity in
outgoing SIP dialogs).
 [0] Transparent = (Default) No intervention in SIP privacy.
 [1] Don't change privacy = The user identity remains the same as in
the incoming SIP dialog. If a restricted number exists, the restricted
presentation is normalized as follows:
 From URL header: anonymous@anonymous.invalid.
