Parameter Description
Notes:
If you enable Syslog, you must enter an IP address of the Syslog
server (using the SyslogServerIP parameter).
Syslog messages may increase the network traffic.
To configure Syslog SIP message logging levels, use the
GwDebugLevel parameter.
By default, logs are also sent to the RS-232 serial port. For how to
establish serial communication with the device, refer to the
Installation Manual.
Web/EMS: Syslog Server
IP Address
CLI: syslog-ip
[SyslogServerIP]
Defines the IP address (in dotted-decimal notation) of the computer on
which the Syslog server is running. The Syslog server is an application
designed to collect the logs and error messages generated by the
device.
The default IP address is 0.0.0.0.
Web: Syslog Server Port
EMS: Syslog Server Port
Number
CLI: syslog-port
[SyslogServerPort]
Defines the UDP port of the Syslog server.
The valid range is 0 to 65,535. The default port is 514.
CLI: mx-syslog-lgth
[MaxBundleSyslogLengt
h]
Defines the maximum size (in bytes) threshold of logged Syslog
messages bundled into a single UDP packet, after which they are sent
to a Syslog server.
The valid value range is 0 to 1220 (where 0 indicates that no bundling
occurs). The default is 1220.
Note: This parameter is applicable only if the GWDebugLevel
parameter is set to 7.
Web: CDR Server IP
Address
EMS: IP Address of CDR
Server
CLI: cdr-srvr-ip-adrr
[CDRSyslogServerIP]
Defines the destination IP address to where CDR logs are sent.
The default value is a null string, which causes CDR messages to be
sent with all Syslog messages to the Syslog server.
Notes:
The CDR messages are sent to UDP port 514 (default Syslog port).
This mechanism is active only when Syslog is enabled (i.e., the
parameter EnableSyslog is set to 1).
Web/EMS: CDR Report
Level
CLI: cdr-report-level
[CDRReportLevel]
Enables media- and signaling-related CDRs to be sent to a Syslog
server and determines the call stage at which they are sent.
[0] None = (Default) CDRs are not used.
[1] End Call = CDR is sent to the Syslog server at the end of each
call.
[2] Start & End Call = CDR report is sent to Syslog at the start and
end of each call.
[3] Connect & End Call = CDR report is sent to Syslog at
connection and at the end of each call.
[4] Start & End & Connect Call = CDR report is sent to Syslog at
the start, at connection, and at the end of each call.
Notes:
For the SBC application, this parameter enables only signaling-
related CDRs. To enable media-related CDRs for SBC calls, use
the MediaCDRReportLevel parameter.
