Parameter Description
The X-RTP-Stat header provides the following statistics:
Number of received and sent voice packets
Number of received and sent voice octets
Received packet loss, jitter (in ms), and latency (in ms)
The X-RTP-Stat header contains the following fields:
PS=<voice packets sent>
OS=<voice octets sent>
PR=<voice packets received>
OR=<voice octets received>
PL=<receive packet loss>
JI=<jitter in ms>
LA=<latency in ms>
Below is an example of the X-RTP-Stat header in a SIP BYE message:
BYE sip:302@10.33.4.125 SIP/2.0
Via: SIP/2.0/UDP
10.33.4.126;branch=z9hG4bKac2127550866
Max-Forwards: 70
From:
<sip:401@10.33.4.126;user=phone>;tag=1c2113553324
To: <sip:302@company.com>;tag=1c991751121
Call-ID: 991750671245200001912@10.33.4.125
CSeq: 1 BYE
X-RTP-Stat:
PS=207;OS=49680;;PR=314;OR=50240;PL=0;JI=600;LA=40;
Supported: em,timer,replaces,path,resource-priority
Allow:
REGISTER,OPTIONS,INVITE,ACK,CANCEL,BYE,NOTIFY,PRACK
,REFER,INFO,SUBSCRIBE,UPDATE
User-Agent: Sip-Gateway-/v.6.2A.008.006
Reason: Q.850 ;cause=16 ;text="local"
Web/EMS: PRACK Mode
CLI: prack-mode
[PrackMode]
Determines the PRACK (Provisional Acknowledgment) mechanism
mode for SIP 1xx reliable responses.
[0] Disable
[1] Supported (default)
[2] Required
Notes:
The Supported and Required headers contain the '100rel' tag.
The device sends PRACK messages if 180/183 responses are
received with '100rel' in the Supported or Required headers.
Web/EMS: Enable Early
Media
CLI: early-media
[EnableEarlyMedia]
Enables the Early Media feature.
Digital: Enables the device to send a 18x response with SDP instead of
a 18x, allowing the media stream to be established prior to the
answering of the call.
Analog: Enables the device to send a 183 Session Progress response
with SDP instead of a 180 Ringing, allowing the media stream to be
established prior to the answering of the call.
[0] Disable (default)
[1] Enable
