AudioCodes Media 800 MSBR

Version 6.6 861 Mediant 800 MSBR
User's Manual 66. Configuration Parameters Reference
Parameter Description
specific rule is defined after a more general rule. For example, if
the digit map is 99|998, then the digit collection is terminated
after the first two 9 digits are received. Therefore, the second
rule of 998 can never be matched. But when the digit map is
99s|998, then after dialing the first two 9 digits, the device waits
another two seconds within which the caller can enter the digit
8.
An example of a digit map is shown below:
11xS|00T|[1-7]xxx|8xxxxxxx|#xxxxxxx|*xx|91xxxxxxxxxx|9011x.T
In the example above, the last rule can apply to International
numbers: 9 for dialing tone, 011 Country Code, and then any
number of digits for the local number ('x.').
Notes:
 For ISDN interfaces, the digit map mechanism is applicable
only when ISDN overlap dialing is used (ISDNRxOverlap is set
to 1).
 If the DialPlanIndex parameter is configured (to select a Dial
Plan index), then the device first attempts to locate a matching
digit pattern in the Dial Plan file, and if not found, then attempts
to locate a matching digit pattern in the Digit Map rules
configured by the DigitMapping parameter.
 For more information on digit mapping, see 'Digit Mapping' on
page 350.
Web: Max Digits in Phone Num
EMS: Max Digits in Phone
Number
CLI: mxdig-b4-dialing
[MaxDigits]
Defines the maximum number of collected destination number
digits that can be received (i.e., dialed) from the Tel side (analog)
when Tel-to-IP ISDN overlap dialing is performed (digital). When
the number of collected digits reaches this maximum, the device
uses these digits for the called destination number.
The valid range is 1 to 49. The default is 5 for analog and 30for
digital.
Notes:
 Instead of using this parameter, Digit Mapping rules can be
configured.
 Dialing ends when any of the following scenarios occur:

Maximum number of digits is dialed

Interdigit Timeout (TimeBetweenDigits) expires

Pound (#) key is pressed
 Digit map pattern is matched
Web: Inter Digit Timeout for
Overlap Dialing [sec]
EMS: Interdigit Timeout (Sec)
CLI: time-btwn-dial-digs
[TimeBetweenDigits]
For analog interfaces: Defines the time (in seconds) that the device
waits between digits that are dialed by the user.
For ISDN overlap dialing: Defines the time (in seconds) that the
device waits between digits that are received from the PSTN or IP
during overlap dialing.
When this inter-digit timeout expires, the device uses the collected
digits to dial the called destination number.
The valid range is 1 to 10. The default is 4.
Web: Enable Special Digits
EMS: Use '#' For Dial
Termination
CLI: special-digits
[IsSpecialDigits]
Determines whether the asterisk (*) and pound (#) digits can be
used in DTMF.
 [0] Disable = Use '*' or '#' to terminate number collection (refer
to the parameter UseDigitForSpecialDTMF). (Default.)

[1] Enable = Allows '*' and '#' for telephone numbers dialed by a
