AudioCodes Media 800 MSBR

Version 6.6 899 Mediant 800 MSBR
User's Manual 66. Configuration Parameters Reference
Parameter Description
spans.
Web/EMS: Idle PCM Pattern
CLI: idle-pcm-pattern
[IdlePCMPattern]
Defines the PCM Pattern that is applied to the E1/T1 timeslot (B-
channel) when the channel is idle.
The range is 0 to 255. The default is set internally according to
the Law select 1 (0xFF for Mu-Law; 0x55 for A-law).
Note: For this parameter to take effect, a device reset is required.
Web/EMS: Idle ABCD Pattern
[IdleABCDPattern]
Defines the ABCD (CAS) Pattern that is applied to the CAS
signaling bus when the channel is idle.
The valid range is 0x0 to 0xF. The default is -1 (i.e., default
pattern is 0000).
Notes:
 For this parameter to take effect, a device reset is required.
 This parameter is applicable only when using PSTN interface
with CAS protocols.
Web/EMS: TDM Bus Clock
Source
[TDMBusClockSource]
Determines the clock source to which the device synchronizes.
 [1] Internal = (Default) Generate clock from local source.
 [4] Network = Recover clock from PSTN line.
Web/EMS: TDM Bus Local
Reference
[TDMBusLocalReference]
Defines the physical Trunk ID from which the device recovers
(receives) its clock synchronization.
The range is 0 to the maximum number of Trunks. The default is
0.
Note: This parameter is applicable only if the parameter
TDMBusClockSource is set to 4 and the parameter
TDMBusPSTNAutoClockEnable is set to 0.
Web/EMS: TDM Bus Enable
Fallback
[TDMBusEnableFallback]
Defines the automatic fallback of the clock.
 [0] Manual (default)
 [1] Auto Non-Revertive
 [2] Auto Revertive
Web: TDM Bus Fallback Clock
Source
EMS: TDM Bus Fallback Clock
[TDMBusFallbackClock]
Determines the fallback clock source on which the device
synchronizes in the event of a clock failure.
 [4] Network (default)
 [8] H.110_A
 [9] H.110_B
 [10] NetReference1
 [11] NetReference2
Web/EMS: TDM Bus Net
Reference Speed
[TDMBusNetrefSpeed]
Defines the NetRef frequency (for both generation and
synchronization).
 [0] 8 kHz (default)
 [1] 1.544 MHz
 [2] 2.048 MHz
Web: TDM Bus PSTN Auto
FallBack Clock
EMS: TDM Bus Auto Fall Back
Enable
[TDMBusPSTNAutoClockEna
ble]
Enables the PSTN trunk Auto-Fallback Clock feature.
 [0] Disable = (Default) Recovers the clock from the E1/T1 line
defined by the parameter TDMBusLocalReference.
 [1] Enable = Recovers the clock from any connected
synchronized slave E1/T1 line. If this trunk loses its
synchronization, the device attempts to recover the clock from
