AudioCodes Media 800 MSBR

User's Manual 976 Document #: LTRT-12809
Mediant 800 MSBR
Parameter Description
added at the end of the coder list.
 [1] Include Extensions = Extension coders and Allowed coders
are arranged according to their order of appearance in the
Allowed Coders Group table.
Note: If the SBCExtensionCodersGroupID parameter of the IP
Profile table is set to None, then this parameter is not applicable.
Web: SBC Send Invite To
All Contacts
CLI: sbc-send-invite-to-all-
contacts
[SBCSendInviteToAllCont
acts]
Enables call forking of INVITE message received with a Request-
URI for a specific contact registered in the device's database, to all
users under the same AOR as the contact.
 [0]
Disable (default) = Sends the INVITE only to the contact of the
received Request-URI.
 [1] Enable
Note: To configure call forking initiated by the device, see Initiating
SIP Call Forking.
Web: SBC Shared Line
Registration Mode
CLI: sbc-shared-line-reg-
mode
[SBCSharedLineRegMode]
Enables the termination on the device of SIP REGISTER messages
from secondary lines pertaining to the Shared Line feature.
 [0]
Disable = (Default) Device forwards the REGISTER messages
as is (i.e., not terminated on the device).
 [1] Enable = REGISTER messages of secondary lines are
terminated on the device.
Note: The device always forwards REGISTER messages of the
primary line.
Web: SBC Forking Handling
Mode
CLI: sbc-forking-handling-
mode
[SBCForkingHandlingMod
e]
Defines the handling of SIP 18x responses received due to call
forking of an INVITE.
 [0] Latch On First = (Default) Only the first 18x is forwarded to the
INVITE-initiating UA. If SIP 18x with SDP is received, the device
opens a voice stream according to the received SDP and
disregards any subsequent 18x forking responses (with or without
SDP). If the first response is 180 without SDP, the device
responds according to the PlayRBTone2TEL parameter and
disregards the subsequent forking 18x responses.
 [1] Sequential = All 18x responses are forwarded, one at a time
(sequentially) to the INVITE-initiating UA. If a 18x arrives with an
offer only, then only the first offer is forwarded to the INVITE-
initiating UA and subsequent 18x responses are discarded.
CLI: sbc-media-sync
[EnableSBCMediaSync]
Enables SBC media synchronization process for calls established
from SIP forking that is initiated by external proxy servers. It is
possible that a call is established with the media not synchronized
between the SBC legs. Media synchronization resolves this issue.
 [0] Disable
 [1] Enable (default)
Admission Control Table
Web: Admission Control
EMS: Call Admission
Control
CLI: configure voip > sbc
sbc-admission-control
[SBCAdmissionControl]
This table parameter defines limitations on the number of allowed
concurrent calls (SIP dialogs). This is useful for controlling bandwidth
utilization between Voice and Data traffic.
The format of this parameter is as follows:
[SBCAdmissionControl]
FORMAT SBCAdmissionControl_Index =
SBCAdmissionControl_LimitType,
SBCAdmissionControl_IPGroupID, SBCAdmissionControl_SRDID,
SBCAdmissionControl_RequestType,
