Version 6.6 981 Mediant 800 MSBR
User's Manual 66. Configuration Parameters Reference
Parameter Description
Web: SAS Connection
Reuse
CLI: sas-connection-reuse
[SASConnectionReuse]
Enables the re-use of the same TCP connection for sessions with the
same user in the SAS application.
[0] Disable
[1] Enable (default)
The device can use the same TCP connection for multiple SIP
requests / responses for a specific SIP UA. The benefits of this feature
include less CPU and memory usage because fewer TCP connections
are open and reduced network congestion. For example, assume the
following:
User A sends a REGISTER message to SAS with transport=TCP.
User B sends an INVITE message to A using SAS.
In this scenario, the SAS application forwards the INVITE request
using the TCP connection that User A initially opened with the
REGISTER message.
Web/EMS: Enable
Record-Route
CLI: record-route
[SASEnableRecordRout
e]
Determines whether the device's SAS application adds the SIP
Record-Route header to SIP requests. This ensures that SIP
messages traverse the device's SAS agent by including the SAS IP
address in the Record-Route header.
[0] Disable (default)
[1] Enable
The Record-Route header is inserted in a request by a SAS proxy to
force future requests in the dialog session to be routed through the
SAS agent. Each traversed proxy in the path can insert this header,
causing all future dialogs in the session to pass through it as well.
When this feature is enabled, the SIP Record-Route header includes
the URI "lr" parameter, indicating loose routing, for example:
Record-Route: <sip:server10.biloxi.com;lr>
Web: SAS Proxy Set
EMS: Proxy Set
CLI: sas-proxy-set
[SASProxySet]
Defines the Proxy Set (index number) used in SAS Normal mode to
forward REGISTER and INVITE requests from users that are served
by the SAS application.
The valid range is 0 to 5. The default is 0 (i.e., default Proxy Set).
Web: Redundant SAS
Proxy Set
EMS: Redundant Proxy
Set
CLI: rdcy-sas-proxy-set
[RedundantSASProxySe
t]
Defines the Proxy Set (index number) used in SAS Emergency mode
for fallback when the user is not found in the Registered Users
database. Each time a new SIP request arrives, the SAS application
checks whether the user is listed in the registration database. If the
user is located in the database, the request is sent to the user. If the
user is not found, the request is forwarded to the next redundant SAS
defined in the Redundant SAS Proxy Set. If that SAS Proxy IP appears
in the Via header of the request, it is not forwarded (thereby,
preventing loops in the request's course). If no such redundant SAS
exists, the SAS sends the request to its default gateway (configured by
the parameter SASDefaultGatewayIP).
The valid range is -1 to 5. The default is -1 (i.e., no redundant Proxy
Set).
Web/EMS: SAS Block
Unregistered Users
CLI: sas-block-unreg-usrs
[SASBlockUnRegUsers]
Determines whether the device rejects SIP INVITE requests received
from unregistered SAS users. This applies to SAS Normal and
Emergency modes.
[0] Un-Block = (Default) Allow INVITE from unregistered SAS
users.
[1] Block = Reject dialog-establishment requests from un-registered
