Benelli TRK 502 Service Station Manual

2 - 11
STANDA RD
FRONT
SUSPENSION
Suspension type
Upside-down fork
with 50 mm diameter tubes
295 mm
150 mm
137 mm
Fork travel
Spring
Free Length
Spacer length
8.6 Nm
Flexibility (K1)
0 ~ 120 mm (0 ~ 4.72 in)
Spring stroke (K1)
SAE 7.5 Marzocchi 19
770 cc.
Fork oil
Recommended oil
Quantity per stem
Level (from the top of the outer
side, with the outer side
completely compressed and
without the fork spring)
95 mm
Angle from one end of stroke to the other (left)
STANDA RD
STEERING
Bearing type for steering
30°
ball bearing
Angle from one end of stroke to the other (right)
30°
TECHNICAL DATA
FRAME SPECIFICATIONS
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
