Benelli TRK 502 Service Station Manual

2 - 12
STANDA RD
REAR SUSPENSION
Suspension type
Swing arm in aluminium alloy, gas-adjustable
shock absorber in hydraulics extended
and spring preloaded
178+/- 1,5 mm
45 mm
Shock absorber fork travel
1200 kPa(12 bar)
Spring preload gas/air standard pressure
Spring
Free Length
Installed length
Flexibility (K1)
Spring stroke (K1)
0
0
Minimum
St an d a r d
10 mm (0.39 in)
Maximum
0
-17
Minimum*
St an d a r d *
- 30
Maximum*
* from the fully retracted position
Quantity of chains
STANDA RD
TRANSMISSION CHAIN
Model (manufacturer)
N.D
N.D
Slackness of transmission chain
N.D
167+/- 1,5 mm
16 Nm
42+/- 1 mm
TECHNICAL DATA
FRAME SPECIFICATIONS
Spring preload adjustment
positions
Rebound damping adjust-
ment positions
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
