Benelli TRK 502 Service Station Manual

2 - 13
TECHNICAL DATA
ELECTRICAL SPECIFICATIONS
SYSTEM VOLTAGE
System voltage
STANDAR D
12 V
STANDAR D
RECHARGE SYSTEM
Primary coil resistance
STANDAR D
IGNITION COILS
Model (manufacturer)
0,65 ± 0,07
Secondary coil resistance
Front position indicator light
STANDAR D
BULBS (VOLTAGE WATT x QTY)
Headlamp (High beam/low beam light)
12 V 55 W x 2
Ohm
4 ± 0,5
kOhm
Model (manufacturer)
System type
QJ
Magnetic AC
Voltage regulation
13.5 + 0.5 V (3000 rpm 25 C°)
Rated output
12.8 V a 1400 rpm 14A
STANDAR D
IGNITION RELAY
Amperage
Model (manufacturer)
100 A
Coil resistance
4.4 Ohm a 20°C
Secondary coil inductance
Primary coil inductance
4.7 H
1,8 mH
Max. allowable current value
10 A
STANDAR D
BATTERY
Voltage of battery capacity
Model (manufacturer)
12 V / 8 Ah
YTX9-BS
STANDAR D
HEADLAMP
Headlamp type
halogen lamp
Inrush current CCA
120A
Direction indicators
Rear position indicator light/brake light LED
License plate light
12 V 5 W x 1
LED
QJ
LED
QJ
COPY - Moto GB - Grant Martland - grantmartland@motogb.co.uk

Benelli TRK 502 Specifications

General

Displacement	500 cc
Transmission	6-speed
Fuel Tank Capacity	20 liters
Seat Height	800 mm
Wet Weight	235 kg
Bore x Stroke	69 mm x 66.8 mm
Compression Ratio	11.5:1
Clutch	Wet multi-plate
Frame	Steel trellis
Wheelbase	1505 mm
Ground Clearance	190 mm
Max Power	47.6 hp (35 kW) @ 8500 rpm
Max Torque	46 Nm @ 6000 rpm
Front Suspension	50 mm upside-down fork
Front Brake	Double floating discs, 320mm, 4-piston calipers
Rear Brake	Single 260 mm disc
Fuel System	Electronic Fuel Injection (EFI)
ABS	Dual-channel ABS
Front Tire	120/70 R17
Rear Tire	160/60 R17
Engine Type	Liquid-cooled, four-stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
