Paging

Note: The “##” prefix is used to indicate multi-facility paging operations.

Description DTMF Code Required CoS

Multi-Site Emergency All-Call Page

##0911

Emergency All-Call

Multi-Site Paging

Multi-Site All Call Page ##0 All-Call Paging

Multi-Site Paging

Emergency All-Call Page

#0911

Emergency All-Call

Multi-Facility Emergency All-Call Page ##0912{facility-page-number}*{facility-

page-number}...

Emergency All-Call

Multi-Site Paging

Emergency All-Call Page 951 Emergency All-Call

All-Call Page

All-Call Paging

#00 All-Call Paging

0000000 All-Call Paging

Real-time All-Call Page that belongs to a queue

#0*

All-Call Paging

0000001

All-Call Paging

Page to {zone}

#{zone}

Zone Paging

0000099{zone}

Zone Paging

Real-time Page to {zone} that belongs to a queue

#{zone}*

Zone Paging

Main Page
