59
Nyquist C4000 User Guide
Editing Tones
You can edit parameters of existing tones, but which parameters can be changed depends on whether
the tone is a default tone or a user-added tone. For example, you cannot change the Name for a default
tone, but you can change it for a tone that you added. You also cannot change the Type of a tone if it is
used in a routine. Some parameters appear only for Line Input tones.
Note: The navigation bar does not appear if you are not authorized to make changes to the C4000 con-
figuration. Contact your system administrator or refer to the Nyquist C4000 System Administrator Guide.
Table 18. Add Tone Page Parameters (Line Input)
Name Provide a name for this tone.
Note: Valid characters include uppercase letters (A–Z), lowercase letters (a–z), numerals
(0–9), space, and the following special characters: !@$*?-.,.
Type Select if the announcement to follow is a normal or an emergency
announcement.
Hide Specify if the tone is to be hidden or displayed on the dashboard view.
Length Enter the number of seconds for the tone to play. The length can range
from 0 to 999999.
Note: A setting of 0 results in the file playing continuously until it is manually stopped via
the dashboard.
DTMF Code Provide the DTMF code used when manually activating the tone via dash-
board dial pad or IP phone keypad.
Amplifiers/Matrix
Mixers
Use the drop-down menu to select the two- or four-channel audio power
amplifier or MMPA and its associated station number.
Input Channel Specify the matrix channel being used for input.
