55
Nyquist C4000 User Guide
Generating Tones
Generating a one-frequency tone is another way to add a tone if you do not want to use the default
tones and do not have a way to upload a tone from a network or removable media location.
Note: The navigation bar does not appear if you are not authorized to make changes to the C4000 con-
figuration. Contact your system administrator or refer to the Nyquist C4000 System Administrator Guide.
Table 16. Add Tone Page Parameters (Upload)
Name Provide a name for this tone.
Note: Valid characters include uppercase letters (A–Z), lowercase letters (a–z), numerals
(0–9), space, and the following special characters: !@$*?-.,.
Type Use the drop-down menu to select if the tone is Normal or Alarm.
Hide Specify if the tone is to be hidden or displayed on the dashboard view.
Times to Play Select the number of times the tone will play. Parameters are 0 through
10.
Note: A setting of 0 results in the tone playing continuously until it is manually stopped
via the dashboard.
Time Between Repeats
(Seconds)
Select the time in seconds between replaying of the tone. You can select
between 0.5 and 5.0 in 0.5 increments.
DTMF Code Provide the DTMF code used when manually activating the tone via dash-
board dial pad or IP phone keypad.
File Upload Select Choose File, navigate to the audio file, and then select the file.
