Brother HL-5590DN Service Manual

2-96
Confidential
 Paper jams in the ejecting section
<User Check>
• Check that the paper is set in each paper tray correctly.
• Flip over the paper in each paper tray or rotate the paper 180°.
• Adjust the paper guide according to the paper size.
• Check that there is not too much paper set in each paper tray.
• Check that the thickness of the paper is 60 to 105 g/m
2
.
• Flip through the paper and reset it in each paper tray.
Step Cause Remedy
1
Foreign object in the rear of the
machine
Remove the foreign object.
2 Eject actuator coming off Reattach the eject actuator.
3
Connection failure of the eject
sensor harness
Reconnect the eject sensor harness.
4
Connection failure of the eject
motor harness
Reconnect the eject motor harness.
5
Connection failure of the MX
motor harness
Reconnect the MX motor harness.
6
Connection failure of the MX
switching solenoid harness
Reconnect the MX switching solenoid harness.
7 Fuser cover attachment failure Reattach the fuser cover.
8
MX switching flapper
attachment failure
Reattach the MX switching flapper.
9 Eject sensor failure Replace the eject sensor PCB ASSY.
10 MX switching solenoid failure Replace the MX switching solenoid.
11 Eject motor failure Replace the eject motor.
12 MX motor failure Replace the MX motor.
13
Damaged gears in the ejecting
system
Replace the main frame L ASSY.
14 Damaged gears inside the MX Replace the MX.
15 Fuser unit failure Replace the fuser unit.
16 Main PCB failure Replace the main PCB ASSY.
