3-7
Confidential
Under bar ground plate R
(T1: Models with 520-sheet)
Taptite cup S M3x8 SR
(Fastening side of LV shield
plate)
1
0.6±0.1 (6±1)
Under bar front
(T1: Models with 250-sheet)
Taptite cup S M3x8 SR
(Fastening side of LV shield
plate)
1
0.6±0.1 (6±1)
LV shield plate Taptite bind B M4x12 1 0.8±0.1 (8±1)
Hold cover 1 Taptite bind B M4x12 1 0.8±0.1 (8±1)
Pinch ground spring Taptite pan B M3x8 1 0.5±0.1 (5±1)
Hold cover 2 Taptite bind B M4x12 2 0.8±0.1 (8±1)
Under bar front
(T1: Models with 520-sheet)
Taptite bind B M4x12
2
0.8±0.1 (8±1)
Under bar ground
plate L
Under bar ground
plate R
Under bar cover
Under bar rear
(T1: Models with 520-sheet)
Taptite bind B M4x12
2
0.8±0.1 (8±1)
Under bar center
(Touch panel models)
Taptite bind B M4x12
2
0.8±0.1 (8±1)
Top bar rear
(Touch panel models)
Taptite bind B M4x12
2
0.8±0.1 (8±1)
Under bar ground plate L
(T1: Models with 520-sheet)
Taptite cup S M3x8 SR
(Fastening side of drive sub
ASSY)
1
0.6±0.1 (6±1)
Under bar front
(T1: Models with 250-sheet)
Taptite cup S M3x8 SR
(Fastening side of drive sub
ASSY)
1
0.6±0.1 (6±1)
Taptite bind B M4x12 2 0.8±0.1 (8±1)
Main frame L ASSY Taptite cup S M3x8 SR 4 0.8±0.1 (8±1)
Taptite bind B M4x12 4 0.8±0.1 (8±1)
Drive sub ASSY Taptite bind B M4x12 8 0.8±0.1 (8±1)
Paper feed motor plate Taptite cup S M3x8 SR 4 0.8±0.1 (8±1)
Paper feed motor Screw bind M3x4 3 0.65±0.05 (6.5±0.5)
MP solenoid Taptite bind B M3x10 1 0.5±0.1 (5±1)
Main PCB shield calking ASSY Taptite bind B M4x12 3 0.8±0.1 (8±1)
Touch panel models Taptite cup S M3x8 SR 3 0.6±0.1 (6±1)
Non touch panel models
Taptite cup S M3x8 SR 2 0.6±0.1 (6±1)
MX holder plate
(Touch panel models)
Taptite bind B M4x12
3
0.8±0.1 (8±1)
Eject motor plate Taptite bind B M3x10 2 0.5±0.1 (5±1)
Eject motor Screw bind M3x4 1 0.65±0.05 (6.5±0.5)
Bottom frame L
(T1: Models with 520-sheet)
Taptite bind B M4x30
3
0.8±0.1 (8±1)
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
To Next Page
