Brother HL-5590DN Service Manual

3-8
Confidential
Base plate Screw pan (S/P washer)
M3x12 DB
2
0.6±0.1 (6±1)
Taptite bind B M4x12 4 0.8±0.1 (8±1)
High-voltage power supply PCB
ASSY
Taptite bind B M4x12
2
0.8±0.1 (8±1)
T1 paper feed actuator holder
ASSY
Taptite bind B M3x10
1
0.5±0.1 (5±1)
Main frame R Taptite bind B M4x12 5 0.8±0.1 (8±1)
MP feed frame Taptite bind B M3x10 2 0.5±0.1 (5±1)
MP paper empty sensor PCB
ASSY
Taptite bind B M3x10
1
0.5±0.1 (5±1)
Paper empty sensor PCB ASSY
(Models with 520-sheet T1 and
HL-5580D/5585D)
Taptite bind B M3x10
1
0.5±0.1 (5±1)
LT side cover L Taptite bind B M4x12 2 0.8±0.1 (8±1)
LT side cover R Taptite bind B M4x12 2 0.8±0.1 (8±1)
LT front cover ASSY Taptite cup S M3x8 SR 1 0.8±0.1 (8±1)
Under bar front
(Models with 520-sheet)
Taptite bind B M4x12
2
0.8±0.1 (8±1)
Under bar ground plate L (520) Taptite cup S M3x8 SR 1 0.8±0.1 (8±1)
Under bar front
(Models with 250-sheet)
Taptite bind B M4x12 2 0.8±0.1 (8±1)
Taptite cup S M3x8 SR (3a) 1 0.8±0.1 (8±1)
Taptite cup S M3x8 SR (3b) 1 0.6±0.1 (6±1)
Under bar Taptite bind B M4x12 2 0.8±0.1 (8±1)
Center FG plate L Taptite cup S M3x8 SR (5a) 1 0.8±0.1 (8±1)
Taptite cup S M3x8 SR (5b) 1 0.6±0.1 (6±1)
Under bar ground plate L (250) Taptite cup S M3x8 SR 2 0.8±0.1 (8±1)
LT frame L unit Taptite bind B M4x12 4 0.8±0.1 (8±1)
Taptite cup S M3x8 SR (7a) 4 0.8±0.1 (8±1)
Taptite cup S M3x8 SR (7b) 2 0.6±0.1 (6±1)
LT drive ASSY Taptite bind B M4x12 3 0.8±0.1 (8±1)
Center FG plate R Taptite cup S M3x8 SR (1a) 1 0.8±0.1 (8±1)
Taptite cup S M3x8 SR (1b) 1 0.6±0.1 (6±1)
LT paper feed frame Taptite cup S M3x8 SR 4 0.6±0.1 (6±1)
Paper feed frame FG
plate R
1
0.6±0.1 (6±1)
LT front beam Taptite bind B M4x12 2 0.8±0.1 (8±1)
LT paper feed actuator holder
ASSY
Taptite bind B M3x10
1
0.5±0.1 (5±1)
LT paper empty sensor PCB
ASSY
Taptite bind B M3x10
1
0.5±0.1 (5±1)
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
