Brother HL-5590DN Service Manual

3-9
Confidential
 Screw torque list (MX)
 Screw torque list (TT)
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
Side cover R MX Taptite cup B M3x10 2 0.5±0.1 (5±1)
Side cover L MX Taptite cup B M3x10 2 0.5±0.1 (5±1)
Top cover MX Taptite cup B M3x10 4 0.5±0.1 (5±1)
MX FG harness R Screw cup M3x8 (Black) 1 0.5±0.1 (5±1)
Drive frame MX Taptite bind B M4x12 7 0.8±0.1 (8±1)
MX switching solenoid Taptite bind B M3x10 1 0.5±0.1 (5±1)
MX bin switching solenoid Taptite bind B M3x10 3 0.5±0.1 (5±1)
MX control PCB ASSY Taptite bind B M3x10 4 0.5±0.1 (5±1)
MX FG harness L Screw cup M3x8 (Black) 1 0.5±0.1 (5±1)
Screw pan (S/P washer)
M3x12 DB
1
0.5±0.1 (5±1)
MX connector holder ASSY Taptite bind B M3x10 4 0.5±0.1 (5±1)
MX motor drive ASSY Taptite bind B M4x12 2 0.8±0.1 (8±1)
MX motor Screw bind M3x4 3 0.7±0.1 (7±1)
MX bin stack sensor holder Taptite bind B M3x10 8 0.5±0.1 (5±1)
Bin detection sensor cover Taptite bind B M3x10 2 0.5±0.1 (5±1)
Arm L MX Taptite bind B M4x12 3 0.8±0.1 (8±1)
Gear holder MX Taptite bind B M4x12 1 0.8±0.1 (8±1)
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
Top cover TT Shoulder screw 8 0.8±0.1 (8±1)
Taptite bind B M4x10 2 0.8±0.1 (8±1)
Side cover L Taptite bind B M4x10 7 0.8±0.1 (8±1)
Side cover R Taptite bind B M4x10 7 0.8±0.1 (8±1)
Back cover Shoulder screw (Black) 6 0.8±0.1 (8±1)
PCB cover plate Screw cup M3x8 (Black) 3 0.5±0.1 (5±1)
TT control PCB ASSY Screw cup M3x8 (Black) 4 0.5±0.1 (5±1)
PCB shield plate Screw cup M3x8 (Black) 6 0.8±0.1 (8±1)
Attach sensor holder (L side) Taptite cup S M3x8 SR 1 1.0±0.1 (10±1)
Attach sensor holder (R side) Taptite cup S M3x8 SR 1 1.0±0.1 (10±1)
Reinforcing plate top L Taptite cup S M3x8 SR 6 1.0±0.1 (10±1)
FG plate L Taptite cup S M3x8 SR 4 1.0±0.1 (10±1)
Motor plate calking ASSY Taptite bind B M4x10 4 0.8±0.1 (8±1)
TT motor Screw bind M3x4 3 0.65±0.05 (6.5±0.5)
Air duct Taptite bind B M4x10 1 0.8±0.1 (8±1)
TT ground plate right Screw pan (S/P washer)
M3.5x6
1
0.5±0.1 (5±1)
Screw cup M3x8 (Black) 1 0.8±0.1 (8±1)
