3-10
Confidential
TT ground plate rear Screw cup M3x8 (Black)
(Left)
1
0.8±0.1 (8±1)
Screw cup M3x8 (Black)
(Right)
1
0.5±0.1 (5±1)
T2TT unit Taptite cup S M3x8 SR 8 1.0±0.1 (10±1)
Taptite bind B M4x10 2 0.8±0.1 (8±1)
Screw cup M3x8 (Black) 6 0.8±0.1 (8±1)
Positioning plate calking ASSY
(Four parts)
Taptite cup S M3x8 SR
8
1.0±0.1 (10±1)
Reinforcing plate L (1/2) Taptite cup S M3x8 SR 6 1.0±0.1 (10±1)
FG plate L Taptite cup S M3x8 SR 4 1.0±0.1 (10±1)
Calking gear plate ASSY Taptite bind B M4x12 4 0.8±0.1 (8±1)
T3TT unit Taptite cup S M3x8 SR 3 0.8±0.1 (8±1)
Taptite bind B M4x10 2 0.8±0.1 (8±1)
LV shield plate cover Screw pan (S/P washer)
M3.5x6
1
0.5±0.1 (5±1)
Screw cup M3x8 (Black) 2 0.5±0.1 (5±1)
Ground harness Screw pan (S/P washer)
M3.5x6
1
0.5±0.1 (5±1)
Inlet Taptite flat B M3x10 2 0.5±0.1 (5±1)
Inlet cover Taptite bind B M3x10 1 0.5±0.1 (5±1)
Low-voltage power supply PCB
ASSY
Screw cup M3x8 (Black)
2
0.5±0.1 (5±1)
Positioning plate calking ASSY
(Four parts)
Taptite cup S M3x8 SR
8
1.0±0.1 (10±1)
Reinforcing plate L (2/2) Taptite cup S M3x8 SR (Left) 3 0.8±0.1 (8±1)
Taptite cup S M3x8 SR
(Right)
3
1.0±0.1 (10±1)
Screw bind M5x8 3 0.8±0.1 (8±1)
Screw cup M3x8 (Black) 4 0.8±0.1 (8±1)
Reinforcing plate R Taptite cup S M3x8 SR 1 1.0±0.1 (10±1)
FG plate L Taptite cup S M3x8 SR 4 1.0±0.1 (10±1)
Calking gear plate ASSY Taptite bind B M4x12 4 0.8±0.1 (8±1)
T4TT unit Taptite cup S M3x8 SR 3 1.0±0.1 (10±1)
Taptite bind B M4x10 2 0.8±0.1 (8±1)
Positioning plate calking ASSY
(Four parts)
Taptite cup S M3x8 SR
8
1.0±0.1 (10±1)
T5TT unit Taptite cup S M3x8 SR 3 1.0±0.1 (10±1)
Taptite bind B M4x10 2 0.8±0.1 (8±1)
TT ground plate Taptite cup S M3x8 SR 2 0.8±0.1 (8±1)
Under bar (Front side) Taptite bind B M4x12 2 0.8±0.1 (8±1)
Under bar ground plate L Taptite cup S M3x8 SR 1 0.8±0.1 (8±1)
Drive ASSY Taptite bind B M4x12 3 0.8±0.1 (8±1)
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
To Next Page
