Brother HL-5590DN Service Manual

5-16
Confidential
C1 T1 paper feed sensor Paper tray 1 closed Paper tray 1 open
P1 T1 paper empty sensor No paper Paper set
MP MP paper empty sensor No paper Paper set
CV Front cover sensor Front cover closed Front cover open
RC Back cover/duplex tray sensor Back cover closed Back cover open
PO Eject sensor No paper Paper set
RM Registration front sensor No paper Paper set
RA Registration rear sensor No paper Paper set
MACxx Internal temperature sensor
XX
C
NG
OTxx External temperature sensor
XX
C
NG
OHxx External humidity sensor XX% NG
S1
MX 1bin stack sensor Ejected paper not yet full Ejected paper full
S2
MX 2bin stack sensor Ejected paper not yet full Ejected paper full
S3
MX 3bin stack sensor Ejected paper not yet full Ejected paper full
S4
MX 4bin stack sensor Ejected paper not yet full Ejected paper full
B2 MX 2bin sensor
MX 2bin paper set MX 2bin no paper
B4 MX 4bin sensor MX 4bin paper set MX 4bin no paper
ML MX JAM lower sensor No paper Paper set
MU MX JAM upper sensor No paper Paper set
C2 T2LT paper feed sensor
(When LT is in use)
Paper tray 2 closed Paper tray 2 open
P2 T2LT paper empty sensor
(When LT is in use)
No paper Paper set
C3 T3LT paper feed sensor
(When LT is in use)
Paper tray 3 closed Paper tray 3 open
P3 T3LT paper empty sensor
(When LT is in use)
No paper Paper set
C4 T4LT paper feed sensor
(When LT is in use)
Paper tray 4 closed Paper tray 4 open
LCD Sensor name
Detection status
With display No display
